- Page 1 Getting started...
- Page 2 We hope that your AXESS 3 AIR will bring you many rewarding hours in the air. The AXESS 3 Air is a light and very comfort- able compact harness with Airbag. Excellent...
-
Page 3: Getting Started
Getting started This guide gives you a brief look at using your AXESS 3 AIR, but it does not replace the official manual, where you will find de- tailed instructions about setting up, use in flight, upkeep and service. The manual can be downloaded from www.advance.ch/ax-... - Page 5 • “Getting started” Booklet correct. Optional extra: Delivery includes: • Foot stirrup with speed system • AXESS 3 AIR harness with carbon seat- board • 2 alu main carabiners • Harness/reserve V-connection, and com- bined reserve handle and four-flap inner...
-
Page 6: Adjusting The Harness
Adjusting the harness result in an upright position. Completely All harnesses are delivered set to their basic settings. This is indicated on the shoulder, loosened back straps put the pilot in a re- clined position. ADVANCE recommend the back and leg straps by markings sewn in basic setting. - Page 7 3. Chest strap 4. Leg straps The chest strap sets the distance between The leg straps should be symmetric and set the main support loops (carabiners). The to a length that allows freedom of movement wider the chest strap is opened the more for takeoff.
- Page 8 5. Seatboard The seatboard angle can be quickly set to any position. This is a matter of pilot pref- erence.
- Page 10 AXESS 3 AIR and its Airbag After unpacking the internal AXESS 3 AIR but it should NOT be stored like this. The Airbag fills itself completely with air, without harness should be stored open and not left the need for any special treatment. The Air- compressed in the rucksack.
- Page 11 If the Airbag is found to be damaged it can be replaced. Caution: Before every takeoff check that the Airbag has unfolded itself correctly. Tip: To maintain the protector’s long life we recommend that the AXESS 3 AIR is stored upside down.
- Page 12 Make sure that the reserve does not exceed a reserve does not release faultlessly, even the volume certified for the AXESS 3 AIR: though it conforms to the approved maxi- Size S 3 to 6.5 litres; Size M 3 to 7 litres and mum volume –...
- Page 13 harness will release properly by carrying out a compatibility test. Caution: You must only use the original reserve handle and its at- tached four-flap inner container.
- Page 14 AXESS 3 AIR. This is the only stirrup to have been included Specific fitting instructions are detailed in the in the LTF 91/09 testing process.
-
Page 16: Technical Details
Technical details Pilot height 155-172 165-187 175-202 Seatboard width 35.5 Seatboard length Carabiner heigth Chest strap width 44-54 44-54 44-54 Weight of harness 3.30 3.50 3.65 Load test DIN EN 1651, 120 kg Airbag certification LTF 91/09... -
Page 17: Warranty And Service
You can find the up-to-date version of the tails online. detailed official manual, more advice about safety, and current information including an- Your AXESS 3 AIR has to have a check every swers to frequently asked questions (FAQs) 24 months and should be regularly inspected. on www.advance.ch. - Page 18 advance thun ag www.advance.ch fon +41 33 225 70 10 uttigenstrasse 87 info@advance.ch fax +41 33 225 70 11 ch 3600 thun...
