H
OW TO CONFIGURE PARAMETERS
Pump activation temperature is adjusted using the potentiometer within the range of 25⁰C -
85⁰C. The pump is disabled when the actual temperature drops by 2⁰C below the pre-set value
(set up using the potentiometer). It prevents periodical pump switching due to slight temperature fluctuation
as it would have a negative impact on the life of the pump.
Apart from the potentiometer, the regulator also has two switches - one for activating the device (indicated
by the power supply light) and the other for manual pump activation ( indicated by the manual operation light).
T
ECHNICAL DATA
No
1
Power supply
2
Power consumption
3
Ambient temperature
4
Circulating pump output load
5
Range of temperature settings
6
Accuracy of measurement
7
Thermal resistance of the sensor
8
Sensor cord length
The regulator has a WT 1,6A tube fuse-link protection.
6
Specification
Unit
V
230 +/-10% /50Hz
W
1
O
C
0 ÷ 50
A
1
O
C
25 ÷ 85
O
C
1
O
C
-25 ÷ 90
m
1,5
