BE7700
BRINKMANN-Suction Pumps Series
Brinkmann Pumpen
K. H. Brinkmann GmbH & Co. KG
Friedrichstraße 2
D-58791 Werdohl
Tel.: +49-2392 / 5006-0
Fax.: +49-2392 / 5006-180
Subject to change without prior notice.
 Brinkmann Pumpen

Operating Instructions

(Translation of original)
06/2019
Edition
SB20...SB60
www.brinkmannpumps.de
sales@brinkmannpumps.de
Order - No.: BE7700 ENGLISH
1
9
Page
of

Advertisement

Table of Contents
loading

Summary of Contents for Brinkmann Suction Pumps Series

  • Page 1: Operating Instructions

    BE7700 Operating Instructions (Translation of original) BRINKMANN-Suction Pumps Series SB20…SB60 Brinkmann Pumpen K. H. Brinkmann GmbH & Co. KG Friedrichstraße 2 D-58791 Werdohl Tel.: +49-2392 / 5006-0 www.brinkmannpumps.de Fax.: +49-2392 / 5006-180 sales@brinkmannpumps.de Subject to change without prior notice. Order - No.: BE7700 ENGLISH ...
  • Page 2: Table Of Contents

    Brinkmann-Suction Pumps Series SB20 ... SB60 Contents Indication to the manual ........2 9 Trouble shooter’s guide ........6 Description of product ........2-3 10 Spare part ............7 Safety instructions ..........3 11 Repair ............... 8 Transport and storage ........4 12 Disposal ............
  • Page 3: Safety Instructions

    Technical data Max. del. Max. del. Height Weight Power Noise pressure volume level bar / spec. Type weight 1 l/min H mm dBA / 50 Hz SB20 0.14 SB25 31,5 0.22 SB40 0.22 SB60 0.63 1) Dimensions in accordance with page 4 2) Noise emissions measured in accordance with DIN 45635 at a distance of 1 m The motor is surface-cooled and compliant with...
  • Page 4: Transport And Storage

    Signs on the pump It is imperative that signs affixed to the machine, e.g.: • arrow indicating the direction of rotation • symbols indicating fluid connections be observed and kept legible. Unauthorized alterations and production of spare parts Any modification may be made to the machine only after consultation with the manufacturer.
  • Page 5: Start Up / Shut Down

    Electric wiring 6 Start up / Shut down Start up ATTENTION Switch off at the mains. All service work must be carried out by quali- After connection the electrical wires, close the fied service personnel. Pump must be discon- terminal box. Briefly start the motor (max. 30 sec.) nected from the power source and all rotating and check the rotation according to the arrow on parts must stand still.
  • Page 6: Trouble Shooter's Guide

    9 Trouble shooter’s guide Fault Cause Remedy Motor does not start, no motor At least two of the power supply Check fuses, terminals and supply leads have failed leads . noise Overload has tripped Inspect overload Motor does not start, humming noise One of the supply leads has failed See above Impeller faulty...
  • Page 7: Spare Part

    10 Spare part 10.1 Spare part list for the suction pumps series SB20...SB60 Item Description Stator with terminal board Pump body Motor flange / SB60 Canal cover Intake cover Impeller End shield / SB60 Terminal box Shaft with rotor 10 Fan 11 Fan cover 12 Retaining ring / SB60 13 Stud bolt with bond / SB60...
  • Page 8: Repair

    11 Repair Brinkmann Suction Pumps series SB20...SB60 Exchange the rotary mechanical seal: 12)Push the rotary mechanical seal part (23a-23d) 1) Disconnect the pump from the power supply. (single part) onto the pump shaft (9) and se- Check up the marks on the pump unit.
  • Page 9: Ec Declaration Of Conformity

    EC declaration of conformity / Déclaration de conformité CE / Declaración de conformidad CE Hersteller / Manufacturer / Constructeur / Fabricante Brinkmann Pumpen, K. H. Brinkmann GmbH & Co. KG Friedrichstraße 2, D-58791 Werdohl Produktbezeichnung / Product name / Désignation du produit / Designación del producto Saugpumpen / Suction pumps / Pompes aspirantes / Bombas aspirantes SB20 …...
