Development Kit User Guide
AirPrime HL6528x
4114877
1.0
November 21, 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AirPrime HL6528 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sierra Wireless AirPrime HL6528 Series

Summary of Contents for Sierra Wireless AirPrime HL6528 Series

  • Page 1 Development Kit User Guide AirPrime HL6528x 4114877 November 21, 2013...
  • Page 2 Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the Sierra Wireless modem are used in a normal manner with a well-constructed network, the Sierra Wireless modem should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property.
  • Page 3 This product may contain technology developed by or for Sierra Wireless Inc. ® This product includes technology licensed from QUALCOMM This product is manufactured or sold by Sierra Wireless Inc. or its affiliates under one or more patents licensed from InterDigital Group and MMP Portfolio Licensing. Copyright ©...
  • Page 4 Development Kit User Guide Document History Version Date Updates November 21, 2013 Creation 4114877 Rev 1.0 November 21, 2013...

  • Page 5: Table Of Contents

    Contents 1. OVERVIEW ......................6 1.1. Embedded Module Support ....................6 1.2. Component Placement ...................... 7 1.3. Features ..........................7 2. CONFIGURATIONS AND SETTINGS ..............9 2.1. Development Kit ........................ 9 2.2. Socket Board ........................11 3. GETTING STARTED WITH THE HL SERIES DEVELOPMENT KIT ....12 3.1.

  • Page 6: Overview

    1. Overview This document describes the AirPrime HL Series Development Kit (board version 1400897-B) and how it integrates with the AirPrime HL6528x series of embedded modules via a socket board (board version 1400922-A). Figure 1. AirPrime HL Series Development Kit (board version 1400897-B) 1.1.

  • Page 7: Component Placement

    Development Kit User Guide Overview 1.2. Component Placement Refer to the following figure for the component placement on the AirPrime HL6528x Development Kit. Figure 2. Development Kit Component Placement 1.3. Features The table below enumerates the different features available on the AirPrime HL Series Development Kit.
  • Page 8 Development Kit User Guide Overview Connector / Features Description/Configuration Switch Power on (POK_IN) SW601 Low level active 2 seconds debouncing Analog audio CN1105 Digital audio (PCM) CN1100 Real time clock backup battery CN406  Pin 1 is ADC0 input, 0-3V ADC0, ADC1 CN300 ...

  • Page 9: Configurations And Settings

    2. Configurations and Settings The AirPrime HL Series Development Kit board automatically adapts to either 2.8V or 1.8V HL6528x variants. 2.1. Development Kit The following table enumerates and describes the jumpers and switches on the AirPrime HL Series Development Kit. Table 3.
  • Page 10 SW302  Switch to “GPS ACTIVE ANT SUPPLY ENABLE” to enable GNSS active antenna supply (default setting) SW400 Discharge button for RTC battery. For internal Sierra Wireless use only.  Switch to “UART0” for UART applications (default setting) SW600 ...

  • Page 11: Socket Board

    Development Kit User Guide Configurations and Settings 2.2. Socket Board The socket board is used to interface the HL6528x embedded module with the AirPrime HL Series Development Kit. CN201 CN202 SW201 Figure 3. AirPrime HL6528x Socket Board (with an HL6528 embedded module) Refer to the following table for more information about the connectors and switches available on the HL6528x socket board.

  • Page 12: Getting Started With The Hl Series Development Kit

    3. Getting Started with the HL Series Development Kit This section describes how the AirPrime HL Series Development Kit is set up as well as describes communications testing, making calls and debugging with an embedded module. 3.1. Setting Up the Development Kit Perform the following steps before powering the Development Kit on.
  • Page 13 Getting Started with the HL Series Development Kit User Guide Development Kit 7. Connect a handset to CN1105 for audio communications. 8. Connect a USB cable to USB0 to get NMEA output. 9. Connect a 4V power supply unit to CN402. Note: Make sure that Pin 2 and Pin 3 of CN403, as well as Pin 1 and Pin 2 of CN402 are connected with a jumper when...

  • Page 14: Switching The Development Kit On

    Getting Started with the HL Series Development Kit User Guide Development Kit 3.2. Switching the Development Kit On The Development Kit will automatically be powered on if Pin 1 and Pin 2 of CN601 are connected with a jumper. Otherwise, push SW601 for approximately 1 second to power on the Development Kit. CN601 SW601 Figure 5.

  • Page 15: Make A Voice Call

    Getting Started with the HL Series Development Kit User Guide Development Kit Test communications using a PC terminal emulator (for example, HyperTerminal) by entering AT. The module should answer with OK. Figure 7. Communicating with the AirPrime HL6528x 3.3.2. Make a Voice Call To make a voice call with the Development Kit, follow these steps.
  • Page 16 Getting Started with the HL Series Development Kit User Guide Development Kit 2. From a PC terminal emulator (for example, HyperTerminal), input AT+CPIN?. If the SIM card is ready, the module will respond with +CPIN: READY, otherwise it will return ERROR. 3.

  • Page 17: Other Hardware Settings

    4. Other Hardware Settings 4.1. Getting SpyTracer Debugging Data To get SpyTracer debug data, ensure that:  an RS232 cable is connected to UART0 (CN602), and  SW600 is switched to “UART0” SW600 CN602 Refer to the SpyTracer guideline for more information to get debug logs. 4.2.

  • Page 18: Reference Documents

    5. Reference Documents AirPrime HL6 and HL8 Series AT Commands Interface Guide Reference Number: 4114680 AirPrime HL6528x Product Technical Specification Reference Number: 4114016 4114877 Rev 1.0 November 21, 2013...
