  • Page 1 Sierra Wireless EM7590 Hardware Integration Guide Rev 1...
  • Page 2 Do not operate the Sierra Wireless modem in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, the Sierra Wireless modem MUST BE IN AIRPLANE MODE OR POWERED OFF. When operating, the Sierra Wireless modem can transmit signals that could interfere with various onboard systems.
  • Page 3 Preface Patents This product may contain technology developed by or for Sierra Wireless Inc. This product is manufactured or sold by Sierra Wireless Inc. or its affiliates under one or more patents licensed from MMP Portfolio Licensing. Copyright ©2022 Sierra Wireless. All rights reserved.

  • Page 4: Table Of Contents

    Contents Introduction ........................5 Accessories ........................5 Required Connectors ..................... 5 Power ..........................6 Power Supply ......................... 6 Module Power States ..................... 6 RF Specifications ......................8 RF Connections ......................11 Shielding ......................... 11 Antenna and Cabling ....................11 Ground Connection ...................... 13 Interference and Sensitivity ..................

  • Page 5: Introduction

    Other accessories • For over-the-air LTE testing, ensure that suitable antennas are used. Required Connectors Table 1-1 describes the connectors used to integrate the EM7590 PCI Express Mini Card into your host device. Table 1-1: Required host-module connectors Connnector Type Description •...

  • Page 6: Power

    Power Power Supply The host provides power to the Sierra Wireless EM7590 through multiple power and ground pins. The host must provide safe and continuous power at all times; the module does not have an independent power supply, or protection circuits to guard against electrical issues.
  • Page 7 Power Table 2-1: Module Power States (Continued) State Details • Sleep Normal state of module between calls or data connections • Module cycles between wake (polling the network) and sleep, at network provider-determined interval. • Disconnected Host power source is disconnected from the module and all voltages associated with the module are at 0 V.

  • Page 8: Rf Specifications

    RF Specifications The module, based on Qualcomm's MDM9250 baseband processor, supports data operation on LTE and UMTS networks over the bands described in Table 3-1, with LTE carrier aggregation (CA) as described in Table 3-2and Table 3-3. Table 3-1: Supported RF Bands Bands UMTS ...
  • Page 9 RF Specifications Table 3-2: Carrier Aggregation Downlink Combinations (Continued) 1 Band / 2CC 2 Bands / 2CC 2 Bands / 2CC CA_5B CA_1A-28A CA_7A-20A CA_7A-7A CA_1A-32A CA_7A-28A CA_7B CA_1A-38A CA_7A-32A CA_7C CA_1A-40A CA_7A-42A CA_8B CA_8A-32A CA_1A-41A CA_12A-12A CA_8A-38A CA_1A-42A CA_12B CA_8A-39A CA_2A-4A CA_25A-25A...
  • Page 10 Table 3-3: Carrier Aggregation Uplink Combinations. CA_1C CA_3C CA_5B CA_7C CA_39C CA_41C CA_42C CA_43C CA_48C Rev 1 July 12, 2022...

  • Page 11: Rf Connections

    Hardware Integration Guide RF Connections When attaching antennas to the module: • Use IPEX (20449-001E (MHF4))to attach antennas to connection points on the module. Note: To disconnect the antenna, make sure you use the IPEX MHF4 connector removal tool to prevent damage to the module or coaxial cable assembly. •...
  • Page 12 RF cable and into the antenna. Disabling the Diversity Antenna Certification testing of a device with an integrated EM7590 may require the module’s main and diversity antennas to be tested separately. To facilitate this testing, receive diversity can be enabled/disabled using AT commands: •...

  • Page 13: Ground Connection

    (Radiated Sensitivity Measurement on page 14). Note: The EM7590 is based on ZIF (Zero Intermediate Frequency) technologies. When performing EMC (Electromagnetic Compatibility) tests, there are no IF (Intermediate Frequency) components from the module to consider. Interference From Other Wireless Devices Wireless devices operating inside the host device can cause interference that affects the module.

  • Page 14: Device-Generated Rf Interference

    RF Specifications Proximity of host electronics to the antenna in wireless devices can contribute to decreased Rx performance. Components that are most likely to cause this include: • Microprocessor and memory • Display panel and display drivers • Switching-mode power supplies Device-generated RF Interference The module can cause interference with other devices.

  • Page 15: Radiated Sensitivity Measurement

    To determine the extent of any receiver performance desensitization due to self- generated noise in the host device, over-the-air (OTA) or radiated testing is required. This testing can be performed by Sierra Wireless or you can use your own OTA test chamber for in-house testing.

  • Page 16: Regulatory Compliance And Industry Certifications

    Regulatory Compliance and Industry Certifications The EM7590 module is designed to meet, and upon commercial release, will meet the requirements of the following regulatory bodies and regulations, where applicable: • Federal Communications Commission (FCC) of the United States • The Certification and Engineering Bureau of Industry Canada (IC) •...
  • Page 17 Regulatory Compliance and Industry Certifications 3. The EM7590 module may transmit simultaneously with other collocated radio transmitters within a host device, provided the following conditions are met: · Each collocated radio transmitter has been certified by FCC/IC for mobile application.
  • Page 18 FCC/IC RF exposure guidelines. The end product with an embedded EM7590 module may also need to pass the FCC Part 15 unintentional emission testing requirements and be properly authorized per FCC Part 15.

  • Page 19: Appendix

    Appendix For more details, several references can be consulted, as detailed below. Website Support Check http://source.sierrawireless.com for the latest documentation available. Abbreviations Table A-1: Acronyms and Definitions Acronym or Term Description 3GPP 3rd Generation Partnership Project BeiDou BeiDou Navigation Satellite System A Chinese system that uses a series of satellites in geostationary and middle earth orbits toprovide navigational data.
  • Page 20 Table A-1: Acronyms and Definitions (Continued) Acronym or Term Description GNSS Global Navigation Satellite Systems (GPS, GLONASS, BeiDou, and Galileo) Global Positioning System An American system that uses a series of 24 satellites in middle circular orbit to provide navigational data. Host The device into which an embedded module is integrated HSDPA...
  • Page 21 Hardware Integration Guide Table A-1: Acronyms and Definitions (Continued) Acronym or Term Description UMTS Universal Mobile Telecommunications System Universal Serial Bus Supply voltage WCDMA Wideband Code Division Multiple Access (also referred to as UMTS) Zero Intermediate Frequency Rev 1 July 12, 2022...
