elco THISION L EVO Series System Manual

Flue systems for wall hung condensing boilers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Flue Gas System Guide
Flue systems for wall hung condensing boilers from 33kW to 1040kW in cascade

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THISION L EVO Series and is the answer not in the manual?

Questions and answers

Related Manuals for elco THISION L EVO Series

Summary of Contents for elco THISION L EVO Series

  • Page 1 Flue Gas System Guide Flue systems for wall hung condensing boilers from 33kW to 1040kW in cascade...

  • Page 2: Table Of Contents

    Index 1. Flue Systems Flue information and guidelines…………..Open flue system…………………….…….… Room sealed system…………….…………. Examples of flue gas systems……………... Available flue systems per boiler……….…… 2. Design and sizing information Boiler maximum flue lengths…….……..…...  Thision S Plus………………………...  Thision L Evo……………….………… ...

  • Page 3: Flue Information And Guidelines

    The flue combustion gases are taken from the boiler and terminated at a higher level to the air intake or a different termination location to avoid contaminating the air supply with the flue gas. Elco recommend that single wall plastic flue pipe (PPs) be used for open flue systems.

  • Page 4: Room Sealed System

    Open flue systems continued… When using an open flue system, Elco recommends that an air inlet cover or air filter must be fitted on the air inlet connection on the boiler, to stop any debris entering the air supply and causing issues with the boilers combustion.

  • Page 5: Examples Of Flue Gas Systems

    1.4 Examples of flue gas systems Combustion air External flue gas exhaust. Air drawn from the room. drawn from the room Air/exhaust gas routing through outside wall in the same pressure range. Exhaust gas/fresh air supply system through outside wall. The Terminal outlets from separate combustion and air supply circuits shall fit inside a square of 50 cm for boilers with a heat input to 70 kW and 100 cm with a heat input from 70 up to 100 kW.

  • Page 6: Available Flue Systems Per Boiler

    Available flue systems per boiler Concentric Flue (mm) Plastic Single Pipe Flue (PPs) (mm) Thision S Plus 80/125 100/150 Thision S Plus 80 100             Thision L Evo 80/125 100/150 Thision L Evo 80 100...

  • Page 7: Thision L Evo

    2.1 Boiler maximum flue lengths continued… Thision L Evo 80/125 100/150 Thision L Evo Equivalent length in m Concentric flue Bend R = D Bend R = D gas system 90°/87° 45°/43° 80/125 100/150 Thision L Evo 80 100 110 125 130 Twin pipe flue Equivalent length in m gas system...

  • Page 8: Safe Flue Termination

    2.2 Safe flue termination In this section we aim to advise which laws and guidance are to be used in which situation. This document will not cover every regulation but it will provide guidance as to which regulation applies to certain situations. The guide will look at the more common standards used to advise the requirements for flue and ventilation installations and is not to be used as a standalone reference for regulations relating to flue.

  • Page 9: Igem-Up 10

    If the flue terminates within 2.5 metres of an adjacent structure, the heights will apply to above the adjacent structure. Elco concentric roof terminals terminates 700mm above roof level and therefore the above need not apply. Minimum termination distances relating to numbers 2, 3 & 6...

  • Page 10: Bs6644 - 70Kw To 1.8Mw

    2.4 BS6644 – 70kW to 1.8MW Open Flued Type B and Room sealed Type C Appliances Installed within an Enclosure (Natural ventilation requirements direct to Outside Air.) Flue type Ventilation direct to outside air Ventilation to an internal space Open flue Type B 5 cm²...

  • Page 11: Bs5440 - Up To 70Kw

    2.5 BS5440 – Up to 70kW Air Vent Position Appliance Input Fanned Draught (kW) Distance (mm) 0 to 7 Above a >7 to 14 Terminal >14 to 32 >32 0 to 7 Below a >7 to 14 Terminal >14 to 32 >32 0 to 7 Horizontally to...
  • Page 12 2.5 BS5440 – Up to 70kW continued… No part of the chimney outlet shall be less than 1500mm measured horizontally to the roof surface or 600mm above the ridge. If the chimney penetrates the dotted area, and distance A is less than 1500mm, then distance B shall not be less than 600mm.

  • Page 13: Available Flue Components

    3. Flue Components 3.1 Available Flue Components Available Flue Parts: 1. Wall Terminal 2. 2000mm Concentric Pipe 3. 500/1000mm Concentric Pipe 4. 90° Concentric Bend 5. 45° Concentric Bend 6. Vertical Adaptor 7. Roof Terminal 8. Flat Roof Flashing 9. Pitched Roof Flashing 10.

  • Page 14: Thision S Plus Flue Components

    3.2 Thision S Plus Flue Components Concentric Flue Systems Item Flue Component 80/125 100/150 3791646 3791303 1950mm Length 3791641 3791304 1000mm Length 3791642 3791305 500mm Length 3791643 3791306 87°/93° Bend 3791644 3791307 45° Bend 3791645 3791308 Wall Terminal FLUE-B-WALL FLUE-B-EVOWALL 1 + 4 Wall Terminal Kit * 3791309...

  • Page 15: Thision L Evo Flue Components

    100mm to 110mm Increaser 3590307 FLUE0039AA000 100mm to 125mm Increaser 130mm to 125mm Reducer 3590308 130mm Air Inlet Cover 452002300 Elco do not supply 130mm PPs flue, if this is required then please contact a specialist flue supplier. Page 15 of 33...

  • Page 16: Thision L Eco Flue Components

    3.4 Thision L Eco Flue Components Concentric Flue System Item Flue Component 100/150 3791303 1950mm Length 3791304 1000mm Length 3791305 500mm Length 3791306 87°/93° Bend 3791307 45° Bend 3791308 Wall Terminal FLUE-B-EVOWALL 1 + 4 *Wall Terminal Kit 3791309 Roof Terminal 3791617 Flat Roof Slate 3791618...

  • Page 17: Flexible Flue Components

    3.5 Flexible Flue Components At Elco Heating Solutions we can offer a flexible flue solution for when the flue gas system needs to be routed through an existing chimney/void such as in listed buildings where amendments to the building layout cannot be made.

  • Page 18: Cascade Flue Components

    Thision S Plus range, please contact a specialist flue supplier. Elco only supply the cascade flue header as pictured, the flue pipe exiting the cascade flue header will need to be sourced via a flue specialist. The air intake header will be need to be sourced by a flue specialist.
  • Page 19 3.4 Cascade Flue Components continued… Thision L Evo Cascade Flue Accessories Flue Component Part Code Cover for Combustion Air Inlet 100mm 452002280 For L Evo 60 – 120 Models Cover for Combustion Air Inlet 130mm 452002300 For L Evo 140 Model Cascade Flue System Adaptor for Thision L Evo 140 452001760 Thision L Eco Cascade Flue Accessories...

  • Page 20: Concentric Flue Parts Dimensions

    4. Flue Component Dimensions 4.1 Concentric flue parts dimensions Concentric Wall Terminal Part Part Code 80/125 3791635 100/150 3791309 110/150 3791768 Concentric Roof Terminal Part Part Code 80/125 3791635 1150 Concentric Roof Terminal Part Part Code 100/150 3791633 1195 110/150 3791659 1195 Page 20 of 33...
  • Page 21 4.1 Concentric flue parts dimensions continued… Concentric 90° Bend Part Part Code 80/125 3791643 100/150 3791306 110/150 3791623 Concentric 45° Bend Part Part Code 80/125 3791644 100/150 3791307 110/150 3791624 1000mm Concentric Straight Length Part Part Code 80/125 3791641 1000 100/150 3791304 1000...
  • Page 22 4.1 Concentric flue parts dimensions continued… 80/125 to 100/150 Concentric Increaser Part Part Code 80/125 3791664 80/125 to 110/150 Concentric Increaser Part Part Code 80/125 3791659 100/100 to 80/125 Concentric Adaptor Part Part Code 100/100 3791648 130/130 to 110/150 Concentric Adaptor Part Part Code 130/130...

  • Page 23: Pps Flue Parts Dimensions

    4.2 PPS flue parts dimensions 2000mm PPs Straight Length Part Part Code 3791584 1950 1895 3791593 1945 1890 3791345 1950 1895 3791609 2075 2000 1000mm PPs Straight Length Part Part Code 3791573 3791299 3791595 1000 3791608 1075 1000 500mm PPs Straight Length Part Part Code 3791585...
  • Page 24 4.3 Accessory parts dimensions Stainless Steel Mesh Terminal Part Part Code 90mm AT-3791582 120mm AT-3791607 160mm AT-3791619 200mm AT-3791620 Flat Roof Flashing Part Part Code 80/125 AT-3791613 100/150 AT-3791617 Pitched Roof Flashing α (°) Part Part Code 80/125 AT-3791614 25° - 45° 25°...

  • Page 25: Flexible Flue Dimensions

    4.4 Flexible flue dimensions 80mm Flexible Flue Liner Part Part Code 12.5m AT-3791586 12.5m 1490 AT-3791587 1490 110mm Flexible Flue Liner Part Part Code AT-3791598 1490 AT-3791599 1490 Chimney Support Bend Part Part Code 80mm AT-3791591 110mm AT-3791605 100mm to 110mm Increaser Part Part Code 100-110...
  • Page 26 4.4 Flexible flue parts dimensions continued… Chimney Cover for Flexible Flue Part Part Code 80mm FLUEBRCTAA500 110mm FLUECRCTAA500 Flex to Flex Adaptor Part Part Code 80mm FLUEBREFAA600 110mm FLUECREFAA600 Page 26 of 33...

  • Page 27: Cascade Flue Dimensions

    4.5 Cascade flue dimensions The cascade flue kits that are supplied for the Thision L Eco boilers are built from individual kits and then multiplied dependant on how many boilers is in the installation. For example, if you have 4 boilers on an in-line cascade frame then the kit will come with 4 sections of cascade flue and so on.
  • Page 28 4.5 Cascade flue dimensions continued… Thision L Eco DN150 Back to Back Cascade Flue Page 28 of 33...
  • Page 29 4.5 Cascade flue dimensions continued… Thision L Eco DN200 Back to Back Cascade Flue Page 29 of 33...
  • Page 30 4.5 Cascade flue dimensions continued… The cascade flue kits that are supplied for the Thision L Evo boilers is a 2 boiler version of the casade header, however further additional extension kits and are added on depending on how many boilers is in the installation.
  • Page 31 4.5 Cascade flue dimensions continued… DN150 Back to Back Cascade Flue 439mm 684mm 100mm 100mm 100mm 100mm 149mm Centre to Centre 149mm Centre to Centre 1422mm 488mm DN200 Back to Back Cascade Flue DN200 685mm 100mm 100mm 100mm 100mm 149mm Centre to Centre 149mm Centre to Centre 1401mm Page 31 of 33...
  • Page 32 4.5 Cascade flue dimensions continued… DN150 In-Line Cascade Flue Extension DN200 In-Line Cascade Flue Extension 715mm 689mm DN150 DN200 100mm 100mm DN150 Back to Back Cascade Flue Extension 690mm 100mm DN150 100mm DN200 Back to Back Cascade Flue Extension 710mm 100mm DN200 100mm...
  • Page 33 Elco Heating Solutions 3 Juniper West, Fenton Way, Southfields Business Park, Basildon, Essex, SS15 6SJ Tel: 01268 546700 Fax: 01268 888250 www.elco.co.uk This publication is issued subject to alteration or withdrawal without notice. The illustrations and specifications are not binding in detail. All offers and sales are subject to the Company’s current terms and conditions of sale.
