PullRite 20K OE Series Installation Instructions Manual

2010-2015 ford f250-f450
Hide thumbs


Advertisement

2010-2015 Ford F250-F450
20K OE Series Industry
Industry Standard Super 5
#1900
Gross Trailer Weight (Maximum) 16,000 lbs.
Vertical Load Weight (Max. Pin Weight) 4,000 lbs.
#2100
Gross Trailer Weight (Maximum) 20,000 lbs.
Vertical Load Weight (Max. Pin Weight) 5,000 lbs.
#2200
Gross Trailer Weight (Maximum) 24,000 lbs.
Vertical Load Weight (Max. Pin Weight) 6,000 lbs

Installation Instructions

• Fits 2010 – 2015 Ford F250 - F450 with 5
#4442
th

SPECIFICATIONS

• Adapter is located center of the rear axle
Standard Adapter
Industry Standard SuperGlide
#2700
Gross Trailer Weight (Maximum) 16,000 lbs.
Vertical Load Weight (Max. Pin Weight) 4,000 lbs.
#2900
Gross Trailer Weight (Maximum) 18,000 lbs.
Vertical Load Weight (Max. Pin Weight) 4,500 lbs.
#2300
Gross Trailer Weight (Maximum) 24,000 lbs.
Vertical Load Weight (Max. Pin Weight) 6,000 lbs
th
wheel /gooseneck prep kit

Advertisement

loading

  Related Manuals for PullRite 20K OE Series

  Summary of Contents for PullRite 20K OE Series

  • Page 1: Installation Instructions

    2010-2015 Ford F250-F450 20K OE Series Industry Standard Adapter #4442 Industry Standard Super 5 Industry Standard SuperGlide #1900 #2700 Gross Trailer Weight (Maximum) 16,000 lbs. Gross Trailer Weight (Maximum) 16,000 lbs. Vertical Load Weight (Max. Pin Weight) 4,000 lbs. Vertical Load Weight (Max. Pin Weight) 4,000 lbs.
  • Page 2 TABLE OF CONTENTS PLATE ASSEMBLY......................... MOUNTING KIT PARTS LIST…..................... MOUNTING KIT EXPLODED VIEW..................INSTALLATION........................5 YEAR LIMITED WARRANTY……………………………………………..........PRODUCT WARRANTY REGISTRATION................
  • Page 3: Plate Assembly

    See illustration to the right. As a PullRite fifth wheel hitch owner, it is important for you to study and manually operate the Fifth Wheel Plate and Release Handle to better understand the locking action.
  • Page 4 MOUNTING KIT PARTS LIST ITEM PART NUMBER DESCRIPTION QTY. 444203 MOUNTING RAIL – Ford 444201 LH SIDE SUPPORT 444202 RH SIDE SUPPORT 444204 MOUNTING POST ASSEMBLY 010019 STANDARD SHACK PIN 08060001 BASE RAIL RELEASE PIN 13070001 MOUNTING WASHER 98410143 HITCH PIN CLIP 98410127 HITCH PIN CLIP...
  • Page 5 MOUNTING KIT EXPLODED VIEW FRONT FRONT...
  • Page 6: Installation

    The factory installed 5 wheel/gooseneck prep kit can not be easily adjusted. The Pullrite adapter has been created with more than generous tolerance to ease installation but may not be perfectly centered in vehicle.
  • Page 7 INSTALLATION Check parts in box against parts list to insure all components are present. 1. Position the mounting washer (7) on the mounting post location, four places. (Due to manufacturing tolerances of the mounting post location(slot), one may need to remove excessive paint or casting burr.) Make sure bronze washer is fully seated on Mounting Post...
  • Page 8 INSTALLATION 4. Place the Mounting Rails (ISR) (1) into the support rail weldments. Lock the base rails into place with the hitch pin (5) and secure with the pin clip (8). 5. Once hitch pins and clips are secured, set your fifth wheel in the corresponding mounting locations and secure with 1/2"...
  • Page 9: Year Limited Warranty

    PULLIAM ENTERPRISES, INC. hereinafter referred to as “PULLIAM”, warrants to the first retail owner only, this PullRite towing system to be free from defects in materials and workmanship for a period of five (5) years or 31,068 miles (50,000 km) after the installation on purchaser’s vehicle, whichever occurs first.
  • Page 10 Product Warranty Registration As an owner of a PullRite product, you must register your product to be considered for warranty coverage. See Owners Manual for further details. Name: __________________________________________________________________________________ Address: ________________________________________________________________________________ City: State Zip: ____________________________ : ______________ _________________ Email Address:...
