Functions And Controls - Genelec F Two Operating Manual

Subwoofer Bass Roll-Off
placement
Near a wall -2 dB
In a corner -4 dB
Table 1. Suggested Bass Roll-Off settings in
typical situations
VOLUME VOLUME
DOWN UP
SELECT
BUTTONS
POWER
MUTE
Figure 4. F Two remote control
signal so you can use main speakers with
either RCA or XLR input connectors. These
outputs are high pass filtered at 85 Hz (See
chapter Bass Management). Additionally,
the LINK RCA output provides a summed
signal of both channels. Use this connector
as a signal output to the next subwoofer
when you want to connect several sub-
woofers together. See chapter "Using Mul-
tiple Subwoofers" for more information.
System Volume Control Connector
This connector allows connecting the
Genelec 9310A Wired Volume Control
which is available as an accessory. When
connected, the 9310A controls the volume
of the whole system, including the main
speakers.
IR IN Connector
If the F Two is used with an infrared type
remote control (see chapter Use with IR
Remote Controls) and the desired location
of the subwoofer does not allow an unob-
structed line of sight to the receiver located
next to the LED in one of subwoofer's feet,
the IR extension cable provided with the
subwoofer can be connected here. The
receiver end of the cable is then brought
to a location where the IR remote control
reception works conveniently, for instance
close to the IR receiver of a television set
when using the subwoofer and speakers
with a TV.
Main loudspeaker model
G One A
G One B
G One B -10 dB Dip ON
G Two A
G Two B
G Two B -10 dB Dip ON
G Three A
G Three A +10 Dip ON
G Three B
G Three B -10 Dip ON
G Four A
G Four A +10 dB Dip ON
8010A
8010A -10 dB Dip ON
8020A
8020B
8020C
8020D
8030A
8030B
8030C
8040A
8040B
M030
Table 2. Suggested Level switch settings with different main loudspeakers

Functions And Controls

HT Mode
Turn this switch to "ON" when you connect a
sound source with its own volume control to
the analog inputs of the F Two. In this mode
the volume control of the F Two does not
have effect on the analog signals. However,
it works with the digital inputs, so you can
use them to connect other signal sources.
ISS Sensitivity Low
If the Intelligent Signal Sensing (ISS) func-
tion switches the subwoofer on when there
is no audio signal present, turning this
F Two Level Dip switch setting
-10 dB switch +10 dB switch
OFF OFF
OFF OFF
ON OFF
OFF OFF
OFF OFF
ON OFF
OFF OFF
OFF ON
OFF OFF
ON OFF
OFF OFF
OFF ON
OFF ON
OFF OFF
OFF ON
OFF ON
OFF ON
OFF ON
OFF ON
OFF ON
OFF ON
OFF ON
OFF ON
OFF ON
switch to "ON" reduces the triggering sen-
sitivity of the function.
The Intelligent Signal Sensing (ISS) func-
tion monitors the audio signal fed to the
subwoofer. If there is no signal for approxi-
mately 45 minutes, the function switches
the subwoofer to Standby mode, reduc-
ing the power consumption to less than
0.5 Watts. When the signal resumes, the
subwoofer powers up again. There is a
slight delay in the automatic powering up.
In those environments where the subwoofer
is required to be on all of the time, the ISS
ISS
