Product information Packing contents Carefully unpack and verify that you have the items below. Some of the items may not be available depending on your region of purchase. Please check with your place of purchase. ENTER MENU EXIT Projector Remote Warranty card User manual CD without lens...
Brightness is supplied by standard lens. The value will vary depending on lenses being installed. • Brightness output will vary depending on each unit and actual usage. • Please visit the local website from http://www.benq.com for the latest User Manual. Projector exterior view Front and upper side view 1. Foot for adjusting projector level 2.
Terminals Control panel Remote control ZOOM +/- TEST PATTERN FOCUS +/- LENS-SHIFT ENTER Left Right ENTER Down MENU EXIT MENU EXIT BLANK AUTO PC STATUS COMPUTER 1 ASPECT COMPUTER 2 HDMI 1 HDMI 2 3G-SDI HDBaseT DisplayPort CLEAR ID SET FREEZE Numeric buttons...
Installation Lens specifications Model BenQ Part Lens Type Optical spec Throw Ratio Zoom Ratio Weight* Name Number Ultra Short LS1ST4 5J.JCY37.002 F=2.0, f=5.64 mm 0.38:1 Fixed 2,710g Throw LS1ST3 Wide fix 5J.JAM37.011 F=1.85, f=11.6mm 0.76:1 Fixed 910g F=1.96~2.3, LS1ST2 Ultra Wide 5J.JAM37.061...
Page 8
When UST lens is installed to the projector, it is recommended to loosen the screw on the support kit and make the arm movable before adjustment. • The User Manual for UST Lens installation is available from local BenQ website.
Lens shift adjustable range The adjustable range for lens shift is tabulated below and subject to the conditions listed. Model Name Lens Type BenQ Part Number Lens Shift Range -3% ~ +7% Vertical; -5% ~ +5% Horizontal LS1ST4 Ultra Short Throw 5J.JCY37.002 (Central position at 56.5%)
Installation positioning Ceiling mount installation 0.1H Screen Top Shift Range Screen Center Desktop installation Screen Center Shift Range 0.1H Note: • Lens Shift function is not available to LS1ST3 (Fixed Lens). This lens should be used for "zero degree"/"no-offset" applications. See below: Screen Center 117.4 FOR USE WITH LS1ST3 (FIXED LENS) ONLY...
Dimensions Cabinet dimensions AIR IN FRONT RING RELEASE BUTTON FRONT COVER AIR IN BASE COVER REAR COVER AIR OUT REAR IR WINDOW TOP COVER MODEL LOGO NAME PLATE FRONT IR Unit: mm LED STATUS Ceiling mount hole dimensions 6-CEILING MOUNT HOLE M4*0.7 SCREW L=16 mm (MAX.)
Ventilation Ventilation illustration Air inlet Air inlet Air outlet Exhaust vent requirements For proper ventilation of the projector, make sure to leave some space around the projector as shown in the illustration below: 11.8 in / 30 cm 11.8 in / 30 cm or greater or greater AUTO...
Installation notice Interlock switch Do not remove the top cover. Otherwise, the projector will be powered off. Do not remove the projection lens. Otherwise, the projector will be powered off. Voltage switcher Please make sure the Voltage Switch is selected at the right voltage in the region where projector is being used.
PIP matrix Main / PIP Matrix Main Source COMPUTER1 COMPUTER2 HDMI DisplayPort HDBaseT 3G-SDI DVI-D PIP source COMPUTER1 ∆ COMPUTER2 ∆ HDMI ∆ DisplayPort ∆ ∆ ∆ ∆ HDBaseT 3G-SDI ∆ DVI-D O: Allowed combination - : Forbidden combination ∆ : Allowed combination (Pixel rate < 165MHz) Adjustment feet There are four adjuster feet on the bottom of the projector, these can be used if it is necessary to change the projection angle.
LED indication Indicator messages Several indicator messages are used by the projector to alert users about problems with setup or system error. The LEDs on top cover of the projector illustrated below. TEMP LED LED display Projector status Operation tips Normal status Contact with your nearest authorized dealer or service Flashing...
