Summary of Contents for BenQ LU9915
-
Page 1: Installation Guide
LU9915 Digital Projector Installation Guide V1.02 4J.JHG01.001... -
Page 2: Table Of Contents
Cabinet dimensions ......................13 Ceiling mount hole dimensions ..................13 Ceiling mount dimensions (CMG6) ................14 Optional lens dimensions ....................15 LED indication ..................... 16 Please visit below website for latest version of User Manual / Installation Guide. http://business-display.benq.com/ 10/8/18... -
Page 3: Notice
Notice Ventilation illustration Air inlet Air inlet Air outlet Exhaust vent requirements For proper ventilation of the projector, make sure to leave some space around the projector as shown in the illustration below: 11.8 in / 30 cm 11.8 in / 30 cm or greater or greater AU TO... -
Page 4: Voltage Switcher
Minimum 11.8 in / 30 cm Minimum Minimum 39.3 in / 100 cm 19.7 in / 50 cm Voltage switcher Please make sure the Voltage Switch is selected at the right voltage in the region where projector is being used. Note: Default setting is 230V. -
Page 5: Product Information
Brightness is supplied by standard lens. The value will vary depending on lenses being installed. • Brightness output will vary depending on each unit and actual usage. • Please visit the local website from http://www.benq.com for the latest User Manual. -
Page 6: Terminals
Terminals COMPUTER 2 COMPUTER 1 MONITOR OUT 3D SYNC OUT TRIGGER RS-232 B/Pb R/Pr 3G-SDI 3D SYNC IN WIRED REMOTE HDBaseT/LAN DVI-D DISPLAYPORT HDMI • HDBaseT/LAN For connection to RJ45 Cat5/Cat6 Ethernet cable to input uncompressed high-definition video (HD), control signals. •... -
Page 7: Remote Control
Remote control ZOOM +/- TEST PATTERN FOCUS +/- LENS-SHIFT ENTER Left Right ENTER Down MENU EXIT MENU EXIT BLANK AUTO PC STATUS COMPUTER 1 ASPECT COMPUTER 2 HDMI 1 HDMI 2 3G-SDI HDBaseT DisplayPort CLEAR ID SET FREEZE Numeric buttons Remote control ID setting You can set the remote control ID to control the specific projector. -
Page 8: Installation
Installation Lens specifications Model BenQ Part Lens Type Optical spec Throw Ratio Zoom Ratio Weight* Name Number Ultra Short LS1ST4 5J.JCY37.002 F=2.0, f=5.64 mm 0.38:1 Fixed 2,710g Throw LS1ST3 Wide fix 5J.JAM37.011 F=1.85, f=11.6mm 0.76:1 Fixed 910g F=1.96~2.3, LS1ST2 Ultra Wide 5J.JAM37.061... -
Page 9: Projection Table
Wide Fix Lens, Wide Zoom Lens, STD Lens, Semi Long Zoom1, Long Zoom 1 Lens, Long Zoom 2 Lens, Ultra Wide Zoom Lens Lens center Height (B) SCREEN Distance (A) LU9915 5J.JAM37.011 5J.JAM37.021 5J.JAM37.001 5J.JAM37.051 Screen Size Wide Fix Lens... - Page 10 When UST lens is installed to the projector, it is recommended to loosen the screw on the support kit and make the arm movable before adjustment. • The User Manual for UST Lens installation is available from local BenQ website.
-
Page 11: Lens Shift
Lens shift adjustable range The adjustable range for lens shift is tabulated below and subject to the conditions listed. Model Name Lens Type BenQ Part Number Lens Shift Range -3% ~ +7% Vertical; -5% ~ +5% Horizontal LS1ST4 Ultra Short Throw 5J.JCY37.001 (Central position at 56.5%) -
Page 12: Installation Positioning
Installation positioning Ceiling mount installation Screen Top 0.1H Shift Range Screen Center Desktop installation Screen Center Shift Range 0.1H Note: • Lens Shift function is not available to LS1ST3 (Fixed Lens). This lens should be used for "zero degree"/"no-offset" applications. See below: Screen Center 117.4 FOR USE WITH LS1ST3 (FIXED LENS) ONLY... -
Page 13: Dimensions
Dimensions Cabinet dimensions AIR IN FRONT RING RELEASE BUTTON FRONT COVER AIR IN BASE COVER REAR COVER AIR OUT REAR IR WINDOW TOP COVER MODEL LOGO NAME PLATE FRONT IR Unit: mm LED STATUS Ceiling mount hole dimensions 6-CEILING MOUNT HOLE M4*0.7 SCREW L=16 mm (MAX.) -
Page 14: Ceiling Mount Dimensions (Cmg6)
Ceiling mount dimensions (CMG6) 302.5 582.8... -
Page 15: Optional Lens Dimensions
Optional lens dimensions Optional Lens (UST: LSIST4) Optional Lens (WIDE FIX: LSIST3) 582.80 582.80 610.16 872.5 Optional Lens (UWZ: LSIST2) Optional Lens (WIDE: LSIST1) 582.8 582.80 616.5 639.4 Optional Lens (STD: LSISD) Optional Lens (SEMI: LSILT1) 582.80 582.80 590.7 609.90 Optional Lens (LONG1: LSILT2) Optional Lens (LONG2: LSILT3) 582.80... -
Page 16: Led Indication
LED indication Indicator messages Several indicator messages are used by the projector to alert users about problems with setup or system error. The LEDs on top cover of the projector illustrated below. TEMP LED LED display Projector status Operation tips Normal status Contact with your nearest authorized dealer or service Flashing... - Page 17 POWER LED indicator LED display Projector status Operation tips Close AC power turned off Check AC power source and power on the projector. Ready to power on the Green Wait until the projector starts projecting. projector Flashing The projector is cooling Orange down To power on the projector, press the ON key on the...
