NOTE:
Please read all instructions
carefully before using this
product
Marcy Pro
Water-Resistance
Table of Contents
Rower
Safety Notice
NS-6070RW
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
NS-6070RW
Retain This
Manual for
Reference
190613
®
IMPEX
INC.
2801 S. Towne Ave, Pomona, CA 91766
ASSEMBLY &
Tel: (800) 999-8899 Fax: (626) 961-9966
www.marcypro.com
OWNER'S
support@impex-fitness.com
MANUAL
0
© IMPEX INC.
www.marcypro.com
Advertisement
Table of Contents
Related Manuals for Impex Marcy Pro NS-607RW
Summary of Contents for Impex Marcy Pro NS-607RW
-
Page 1: Impex Inc
Assembly Instruction Parts List Warranty Ordering Parts Model NS-6070RW Retain This Manual for Reference 190613 ® IMPEX INC. 2801 S. Towne Ave, Pomona, CA 91766 ASSEMBLY & Tel: (800) 999-8899 Fax: (626) 961-9966 www.marcypro.com OWNER'S support@impex-fitness.com MANUAL © IMPEX INC. www.marcypro.com... -
Page 2: Table Of Contents
To avoid unnecessary delays, please call our TOLL-FREE customer service number. Our Customer Service Agents will provide immediate assistance to you. Toll-Free Customer Service Number 1-800-999-8899 Mon. - Fri. 9 a.m. - 5 p.m. PST www.marcypro.com support@impex-fitness.com © IMPEX INC. www.marcypro.com... -
Page 3: Imporant Safety Notices
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. SAVE THESE INSTRUCTIONS. © IMPEX INC. www.marcypro.com... -
Page 4: Warning Label Placement
WARNING LABEL PLACEMENT The Warning Labels shown here has been placed on the Front Stabilizer. If the labels are missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the labels in location shown. © IMPEX INC. www.marcypro.com... -
Page 5: Pre-Assembly Check List
PRE-ASSEMBLY CHECK LIST NO.1 NO.2 NO.3 NO.46 NO.36 Q’TY PART NO. DESCRIPTION Main frame Rear stabilizer Slide rail Seat Computer © IMPEX INC. www.marcypro.com... -
Page 6: Hardware Pack
HARDWARE PACK #35 Limit pad #58 M8*⅔” 4pcs #60 M8*⅔” 8pcs #66 M8*⅔” 4pcs #71 Φ¾” 12pcs #83 M6*⅔" 2pcs #88 S5 1pc #89 S13-17 1pc © IMPEX INC. www.marcypro.com... -
Page 7: Assembly Instruction
3. Attach the Rear Stabilizer (#2) to the Slide Rail (#3), tighten with 4 Washers (#71) and 4 Hex bolts (#66). # 35 Limit pad 1pc # 66 M8*⅔” 4pcs # 83 M6*⅔" 2pcs #71 Φ¾” 4pcs # 89 S13-17 © IMPEX INC. www.marcypro.com... - Page 8 2. Attach the Slide Rail (#3) to the Main Frame (#1), tighten with 4 Flat Screws (#58), 4 Washers (#71) and 4 Allen Bolts (#60). # 58 M8*⅔" 4pcs # 60 M8*⅔" 4pcs # 71 Φ¾” 4pcs # 88 S5 60 71 © IMPEX INC. www.marcypro.com...
- Page 9 STEP-3 Attach the computer (#46) to Main Frame, tighten with 4 Washers (#71) and 4 Allen Bolts (#60) #60 M8*⅔" 4pcs #71 Φ¾” 4pcs #88 S5 © IMPEX INC. www.marcypro.com...
-
Page 10: Exploded Diagram
EXPLODED DIAGRAM © IMPEX INC. www.marcypro.com... -
Page 11: Parts List
Rubber sealing ring Impeller Shaft Seal Sealing ring for upper tank Fill Plug O-ring Gasket Limiter pad Seat Pedal strap Computer Adjustable Knob Bungee cord Plastic washer One way bearing Bearing Spacer for Guide Roller Bushing Computer © IMPEX INC. www.marcypro.com... - Page 12 Stainless Steel washer Hex nut Small Spacer Spacer for Bungee pulley Aircraft nut M6 x 1½” Adjusting Screw M6 x ⅔" Flat head Screw Computer Support Arm Φ½” Flat washer Pumping Siphon Funnel Allen Wrench Multi-Tool Hex nut © IMPEX INC. www.marcypro.com...
-
Page 13: Care And Maintanence
Filling the tank over this limit will void the warranty. • The resistance depends on the water level in the tank. Water level 1 is the lowest resistance. Level 6 is the highest resistance. Fig.A Fig.B Water level label © IMPEX INC. www.marcypro.com... -
Page 14: Adjustment Guide
3. There are 3 hooks (A, B, C) for the bungee cord. 4. Hook B or C will provide more tension on the belt for a faster return on the rowing handle. Use caution when adjusting the bungee cord. © IMPEX INC. www.marcypro.com... - Page 15 With the wheels on the ground, you can transport the rower to the desired location with ease. To Stabilize the Rower Adjust the Rear Stabilizer of the machine if the machine is unbalanced during use. © IMPEX INC. www.marcypro.com...
-
Page 16: Storage Guide
Seat will slide down. When not in use, you can save space by storing the rower vertically. If you plan to not use the rower for more than a month, empty the tank prior to storing. © IMPEX INC. www.marcypro.com... -
Page 17: Computer
STROKES: Preset target value by pressing UP or DOWN buttons (0~9990 strokes) in 10-stroke increments. TOTAL STROKES: Accumulates total strokes from 0 up to 9999. CALORIES: Set target CALORIES by pressing UP or DOWN buttons (10Cal ~9990Cal) in 10-Cal. increments. © IMPEX INC. www.marcypro.com... - Page 18 When you select MANUAL, the value of TIME will start to flash. Press UP/DOWN to set the value of TIME to countdown. Press ENTER to confirm it. If you do not want to set the value of time to COUNTDOWN, © IMPEX INC. www.marcypro.com...
- Page 19 1. This computer works with a 5.3 KHz chest strap heart rate monitor (not included). After exercising for a period of time, continue wearing chest strap monitor and press “RECOVERY” button. All function displays will stop except “TIME”, it will © IMPEX INC. www.marcypro.com...
-
Page 20: Exercise Guidelines
Each stretch should be held for approximately 30 seconds, do not force or jerk your muscles into a stretch - if it hurts, STOP. INNER THIGH FORWARD BENDS CALF / ACHILLES SIDE BENDS OUTER THIGH © IMPEX INC. www.marcypro.com... -
Page 21: Weight Loss
The important factor here is the amount of effort you put in. The harder and longer you work the more calories you will burn. Effectively this is the same as if you were training to improve your fitness, the difference is the goal. © IMPEX INC. www.marcypro.com... -
Page 22: Warranty
IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
