MODEL PAXLSG - PAX LITE STRAIN GAGE METER /
U
L
C
US LISTED
US LISTED
4
GENERAL DESCRIPTION
The Model PAXLSG expands the PAX Lite capabilities into the indication of
pressure, load, force, and other parameters measured with strain gages. The unit
features broad range scaling and can be used with a wide variety of strain gage
resistances and bridge configurations. A built-in excitation source is jumper
selectable for 5 or 10 VDC @ 120 mA maximum, and can power up to four full
350 Ω bridges in load averaging applications. Although designed primarily for
strain-gage indication, the PAXLSG is also ideal for single-ended or differential
millivolt input applications, with full-scale input ranges from 0 to 10 mV thru 0
to 2 VDC. Adjustable scaling and offset allow direct readout in nearly any
engineering unit.
The meter has a NEMA 4X/IP65 sealed bezel and extensive testing of noise
effects to CE requirements, allowing the meter to provide a tough yet reliable
application solution.
DIMENSIONS In inches (mm)
MILLIVOLT METER
IND. CONT . EQ.
51EB
Note: Recommended minimum clearance (behind the panel) for mounting clip installation is
2.1" (53.4) H x 5.0" (127) W.
3 1/2-DIGIT, 0.56" (14.2 mm) HIGH LED READOUT
HIGH SENSITIVITY, 10 mV FULL SCALE
WIDE RANGE GAIN AND OFFSET ADJUSTMENTS
BUILT-IN EXCITATION 5 OR 10 VDC
APPLICABLE AS REGULAR MILLIVOLT INDICATOR
(Single-ended or Differential Input)
SELECTABLE DECIMAL POINTS
OVER-RANGE INDICATION
NEMA 4X/IP65 SEALED FRONT BEZEL
OPTIONAL CUSTOM UNITS OVERLAY WITH BACKLIGHT
SAFETY SUMMARY
All safety related regulations, local codes and instructions that appear in the
literature or on equipment must be observed to ensure personal safety and to
prevent damage to either the instrument or equipment connected to it. If
equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
CAUTION: Risk of Danger.
Read complete instructions prior to
installation and operation of the unit.
1
Bulletin No. PAXLSG-A
Drawing No. LP0571
Released 12/07
CAUTION: Risk of electric shock.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for red lion PAXLSG
Summary of Contents for red lion PAXLSG
-
Page 1: General Description
GENERAL DESCRIPTION SAFETY SUMMARY The Model PAXLSG expands the PAX Lite capabilities into the indication of All safety related regulations, local codes and instructions that appear in the pressure, load, force, and other parameters measured with strain gages. The unit... - Page 2 ABLE ONTENTS Ordering Information ....2 Wiring the Meter ..... . 5 General Meter Specifications.
- Page 3 ENERAL ETER PECIFICATIONS DISPLAY: 3 1/2-digit, 0.56" (14.2 mm) high, 7-segment LED, (-) minus sign ELECTROMAGNETIC COMPATIBILITY displayed when voltage is negative. Decimal points inserted before 1st, 2nd, Emissions and Immunity to EN 61326: Electrical Equipment for or 3rd least significant digits by DIP switch selection. Measurement, Control and Laboratory use.
- Page 4 FUNCTION only one jumper position is used at a time. Decimal Point 1 (000.0) Decimal Point 2 (00.00) Decimal Point 3 (0.000) Backlight Annunciator for Units Label PAXLSG Jumper Selection FRONT DISPLAY JUMPER SELECTIONS Main indicates factory setting. Circuit D.P./ BACKLIGHT...
-
Page 5: Power Wiring
3.0 W IRING THE ETER WIRING OVERVIEW and portable two-way radios are used in close proximity or if the installation is near a commercial radio transmitter. Electrical connections are made via screw-clamp terminals located on the 3. Signal or Control cables within an enclosure should be routed as far away as back of the meter. - Page 6 Note: Disregarded Decimal Points in Readout. transducers or to intentionally introduce an offset, such as tare-load compensation. For example, if an PAXLSG is to display 50.0 @ 2 mV (min.) and 169.0 @ The Fine Offset Adjustment is a 15-turn screwdriver adjustable potentiometer, 19 mV (max.), the required gain will be:...
-
Page 7: Calibration Procedure
If a zero-based example In this method, the transducer is connected to the input of the PAXLSG in the had been given, the minimum readout and input voltage would have both been final installation, or in a bench set-up simulating the actual installation. -
Page 8: Limited Warranty
EXAMPLE #2 THE MODEL PAXLSG AS A MILLIVOLT METER The PAXLSG can be used as a scaleable millivolt meter and will accept either single-ended or differential inputs when connected as shown. Input signals are referenced to the negative (common) side of the excitation supply (Terminal 3).
