- Page 1 Quick Start Guide 2/4-Port 4K Dual View DisplayPort KVMP Switch with USB 3.0 Hub and Audio GCS1942/GCS1944 PART NO. Q1501/Q1502 www.iogear.com...
-
Page 2: Package Contents
Package Contents GCS1944 GCS1942 1 x GCS1944 1 x GCS1942 8 x DisplayPort 1.2 Cables 4 x DisplayPort 1.2 Cables 4 x USB 3.0 Cables 2 x USB 3.0 Cables 4 x Audio Cable Sets 2 x Audio Cable Sets... - Page 3 Overview GCS1942 Front View 2-Port Dual View DisplayPort KVMP GCS1942 MODE GCS1942 Rear View CONSOLE 1. Port selection pushbuttons 2. Port LEDs 3. Audio Ports 4. USB 3.0 Hub 5. Console Ports 6. KVM Ports 7. Power Jack...
- Page 4 GCS1944 Front View 4-Port Dual View DisplayPort KVMP GCS1944 AUTOSCAN MODE AUDIO AUDIO USB LINK USB LINK GCS1944 Rear View CONSOLE...
-
Page 5: Hardware Installation
Hardware Installation 1. Connect the USB keyboard and mouse to the GCS1942/GCS1944 console ports 2. Connect the two DisplayPort monitors to the GCS1942/GCS1944 console ports 3. Turn the monitor power to ON 4. Connect the main microphone and speakers into the GCS1942/GCS1944 microphone and speaker jacks located on the front side panel. - Page 6 Hardware Installation GCS1942 Rear View CONSOLE GCS1942 Front View 2-Port Dual View DisplayPort KVMP GCS1942 MODE...
- Page 7 GCS1944 Rear View CONSOLE GCS1944 Front View 4-Port Dual View DisplayPort KVMP GCS1944 AUTOSCAN MODE AUDIO AUDIO USB LINK USB LINK...
-
Page 8: Operation
Switching between connected computer sources: a. Manual – involves pressing the port selection pushbuttons located on the GCS1942/GCS1944 front panel. b. Hotkey – involves entering combinations from the keyboard (list of complete Hotkey Settings is available in the manual, located on our website). -
Page 9: Emc Information
EMC Information Federal Communications Commission Statement (FCC) Statement: This equipment has been tested and found to comply with the limits for a Class B digital service, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 10: Limited Warranty
