Installation and Operation Instructions
Vented Gas Log and Burner Set
Models
MAGNIFLAMEOD24NE
For use with log sets
®
SOUTHERNCOMFORT24A/B
US
SOUTHERNCOMFORT30A/B
SOUTHERNCOMFORT36A/B
WARNING: For Outdoor Use Only.
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
MAGNIFLAMEOD24PE
SHADYHOLLOW24A/B
SHADYHOLLOW30A/B
SHADYHOLLOW36A/B
DANGER
P126779-01
Advertisement
Table of Contents
Related Manuals for Astria Fireplaces MAGNIFLAMEOD24NE
Summary of Contents for Astria Fireplaces MAGNIFLAMEOD24NE
- Page 1 Installation and Operation Instructions Vented Gas Log and Burner Set Models P/N 126779-01 REV. D 01/2019 MAGNIFLAMEOD24NE MAGNIFLAMEOD24PE For use with log sets ® SOUTHERNCOMFORT24A/B SHADYHOLLOW24A/B SOUTHERNCOMFORT30A/B SHADYHOLLOW30A/B Report No. 10-87 SOUTHERNCOMFORT36A/B SHADYHOLLOW36A/B WHEN USED AS AN OUTDOOR APPLIANCE WARNING: For Outdoor Use Only.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..................2 Specifications ..............17 Product Identification ............4 Wiring Diagram ..............18 Local Codes.................4 Troubleshooting ..............19 Unpacking................4 Replacement Parts ............22 Product Features ..............5 Service Hints ..............22 Installation ................5 Technical Service...............22 Operation ................15 Accessories ...............22 Inspecting Burners.............16 Parts ..................24 Cleaning and Maintenance ..........17 Warranty ................27 SAFETY WARNING: FIRE, EXPLOSION, AND ASPHYXIATION HAZARD... - Page 3 SAFETY Continued 4. This appliance shall not be installed in a bedroom or bath- Young children should be carefully supervised when room, unless installed as a vented appliance. See Installing they are in the same room with the appliance. When Damper Clamp Accessory for Vented Operation, Page 6.
-
Page 4: Product Identification
PRODUCT IDENTIFICATION LEFT RIGHT SIDE SIDE Figure 1 - Product Identification LOCAL CODES UNPACKING Install and use appliance with care. Follow all local codes. 1. Remove logs and appliance base assembly from carton(s). In the absence of local codes, use the latest edition of The 2. -
Page 5: Product Features
PRODUCT FEATURES INSTALLATION OPERATION OUTDOOR ENCLOSURE REQUIREMENTS This appliance is dual listed as a vented decorative gas appli- This appliance is considered to be installed outdoors if in- ance to ANSI Z21.60 for use indoors in wood burning fireplaces stalled with shelter no more inclusive than: and as an outdoor decorative gas appliance to ANSI Z21.97. - Page 6 INSTALLATION Continued Carefully follow the instructions below. This will ensure safe Noncombustible Requirements for Safe Installation installation into a masonry, UL127-listed manufactured fire- Material Distance place or listed outdoor firebox. Minimum Clearances For Side Combustible Material, Side 12" or more Noncombustible material OK.
- Page 7 INSTALLATION Continued MANTEL CLEARANCES NOTICE: Surface temperatures of adjacent In addition to meeting noncombustible material clearances, walls and mantels become hot during opera- you must also meet required clearances between fireplace tion. Walls and mantels above the firebox may opening and mantel shelf. If you do not meet the clearances become hot to the touch.
- Page 8 INSTALLATION Continued For Massachusetts Residents Only: Installation of this gas Chimney Height Minimum Permanent Flue Opening log set as a vented indoor appliance in the Commonwealth of Massachusetts requires the damper be permanently removed 6' to 15' 39 sq. inches or welded in the fully open position.
- Page 9 INSTALLATION Continued For propane/LP units, the installer must supply an external Masonry Screw regulator. The external regulator will reduce incoming gas pressure. You must reduce incoming gas pressure to between 11" and 14" of water. If you do not reduce incoming gas pres- sure, appliance regulator damage could occur.
- Page 10 INSTALLATION Continued Equipment Shutoff Valve PROPANE/LP 3. Pressurize supply piping system by either opening pro- With 1/8" NPT Tap* From External pane/LP supply tank valve for propane/LP gas or opening Regulator main gas valve located on or near gas meter for natural Approved Flexible (11"...
- Page 11 3. Replace battery cover onto remote control. Grate Finger MF SERIES BURNER SYSTEM LOG COMPATIBILITY CHART Burner System Model Refractory Concrete Logs For Use With This Burner System Figure 16 - Installing Right Front Log SOUTHERNCOMFORT24A/B SOUTHERNCOMFORT30A/B MAGNIFLAMEOD24NE SOUTHERNCOMFORT36A/B MAGNIFLAMEOD24PE SHADYHOLLOW24A/B SHADYHOLLOW30A/B SHADYHOLLOW36A/B Astria.us.com 126779-01D...
- Page 12 INSTALLATION Continued Round Tube Burner 2. Find the back left log (SouthernComfort24 and ShadyHollow24 models: D-060, SouthernComfort30 and ShadyHollow30 models: D-018, SouthernComfort36 and ShadyHollow36 models: D-026). See Figures 17, 17A, and 17B. Figure 17A shows how the log must fit against the end of the burner.
- Page 13 INSTALLATION Continued 3. Find the front left log (SouthernComfort24 and 4. Find the charred log (D-020). See Figures 19, 19A, and ShadyHollow24 models: D-059, SouthernComfort30 and 19B. The log has a slot in the bottom that fits over the ShadyHollow30 models: D-017, SouthernComfort36 and square grate and rests against the burner tube as shown in...
- Page 14 INSTALLATION Continued Square Peg Right Split Crossover 5. Find the middle split log (SouthernComfort24 and Log (D-022) ShadyHollow24 models: D-063, SouthernComfort30 and ShadyHollow30 models: D-021, SouthernComfort36 and ShadyHollow36 models: D-028). See Figures 20 and 20A. The split side of the log faces forward. The log has a notch that fits around the burner tube on the right side.
-
Page 15: Operation
INSTALLATION OPERATION Continued FOR YOUR SAFETY Back Top Log (D-062, READ BEFORE LIGHTING D-023 or D-029) Right Split Crossover WARNING: If you do not follow these instruc- Log (D-022) tions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 16: Inspecting Burners
OPERATION INSPECTING BURNERS Continued Check burner flame patterns often. IGNITER ASSEMBLY The igniter assembly is factory preset for proper ignition of Incoming the burner. Alterations may have occurred during shipping Gas Line Equipment and handling. Call a qualified service person to readjust the Shutoff Valve igniter assembly if necessary. -
Page 17: Cleaning And Maintenance
SPECIFICATIONS by a qualified service person. We also recommend that you keep the burner tube clean and MAGNIFLAMEOD24NE free of dust and dirt. To clean these parts we recommend using • Rating (Variable): 29,000/40,000 Btu/Hr compressed air no greater than 30 PSI. Your local computer •... -
Page 18: Wiring Diagram
WIRING DIAGRAM Green Orange White Orange Igniter HI/LO Pilot Solenoid Black AF-4000 AF-5000MOD Main Control Module AF-4000B/P Black Orange Brown Black Black (GND) Brown Brown These wires are not used on this application Opti Black CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous opera- tion. -
Page 19: Troubleshooting
TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair appliance. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ''ON'' button on remote control 1. - Page 20 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Delayed ignition of burner 1. Manifold pressure is too low 1. Contact local natural or propane/LP gas company 2. Burner orifice clogged 2. Clean burner (see Cleaning and Mainte- nance, Page 16) or replace burner orifice(s) Burner backfiring during combustion 1.
- Page 21 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instruc- tions.
-
Page 22: Replacement Parts
REPLACEMENT PARTS See Pages 22-24 for a complete replacement parts list. Use 1. The model number of the appliance. only parts supplied from the manufacturer. 2. The serial number of the appliance. 3. The part number. Normally, all parts should be ordered through your IHP dis- 4. - Page 23 PARTS MODELS: MAGNIFLAMEOD24NE AND MAGNIFLAMEOD24PE Cat. No. Model F0557 MAGNIFLAMEOD24NE F0559 MAGNIFLAMEOD24PE Astria.us.com 126779-01D...
-
Page 24: Parts
PARTS MODELS: MAGNIFLAMEOD24NE AND MAGNIFLAMEOD24PE This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replace- ment Parts on Page 22 of this manual. Only kits supplied by IHP shall be used in the installation of this appliance. Use of non-approved accessory/part kit(s) can result in poor performance and safety hazards. - Page 25 PARTS LOG SET MODELS SOUTHERNCOMFORT24A/B, SOUTHERNCOMFORT30A/B AND SOUTHERNCOMFORT36A/B This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Re- placement Parts on Page 22 of this manual. SouthernComfort24A/B SouthernComfort30A/B SouthernComfort36A/B CAT. NO. LOG ID NO. CAT.
- Page 26 PARTS LOG SET MODELS SHADYHOLLOW24A/B, SHADYHOLLOW30A/B, AND SHADYHOLLOW36A/B This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on Page 22 of this manual. ShadyHallow24A/B ShadyHallow30A/B ShadyHallow36A/B CAT. NO. Log Id. # CAT.
-
Page 27: Warranty
Innovative Hearth Products Astria Brand Gas Log Set & Outdoor Gas Fire Pit ® Limited Three Year Warranty THE WARRANTY Innovative Hearth Products Limited Three Year Warranty ("IHP") warrants your Astria brand Gas Log Set or Outdoor Gas Fire Pit ("Product") to be free from defects in ®... - Page 28 Astria.us.com Record the following important information about your appliance: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name IHP reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
