P/N 900635-00 REV. A 01/2019
DANGER
WARNING: No not store gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance. An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the installation, operating and maintenance instructions thoroughly before install-
ing or servicing this equipment.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appli-
ance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
PFS
Report No. 10-87
WHEN USED AS AN OUTDOOR APPLIANCE
CARBON MONOXIDE WARNING
•
This appliance can produce carbon
monoxide which has no odor.
•
Using it in an enclosed space can
kill you.
•
Never use this appliance in an en-
closed space such as a camper, tent,
car or home.
WHEN USED AS INDOOR VENTED APPLIANCE
Installation and Operation Instructions
Vented Gas Log Appliance
Remote-Ready Log Set And Burner System Models
Models
MAGNIFLAMEOD30NE
®
For use with log sets
US
SOUTHERNCOMFORT30A/B
SOUTHERNCOMFORT36A/B
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
MAGNIFLAMEOD30PE
SHADYHOLLOW30A/B
SHADYHOLLOW36A/B
WARNING: For Outdoor Use Only.
DANGER
P900635-00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Astria Fireplaces MAGNIFLAMEOD30NE
Summary of Contents for Astria Fireplaces MAGNIFLAMEOD30NE
- Page 1 Installation and Operation Instructions Vented Gas Log Appliance Remote-Ready Log Set And Burner System Models P/N 900635-00 REV. A 01/2019 Models MAGNIFLAMEOD30NE MAGNIFLAMEOD30PE ® For use with log sets SOUTHERNCOMFORT30A/B SHADYHOLLOW30A/B Report No. 10-87 SOUTHERNCOMFORT36A/B SHADYHOLLOW36A/B WHEN USED AS AN OUTDOOR APPLIANCE WARNING: For Outdoor Use Only.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..................2 Specifications ..............16 Product Identification ............3 Wiring Diagram ..............17 Local Codes.................4 Troubleshooting ..............18 Unpacking................4 Accessories ...............21 Product Features ..............4 Replacement Parts ............21 Installation ................4 Service Hints ..............21 Operation ................14 Technical Service...............21 Inspecting Burners.............15 Parts ..................22 Cleaning and Maintenance ..........16 Warranty ................27 SAFETY DANGER: Carbon monoxide poisoning may... -
Page 3: Product Identification
SAFETY Continued You must operate this appliance with the fire- 11.Do not use this appliance to cook food or burn paper or other objects. place screen and hood in place. Make sure 12.Do not use this appliance if any part has been exposed to fireplace screen and hood are in place before or under water. -
Page 4: Local Codes
INSTALLATION LOCAL CODES Install and use appliance with care. Follow all local codes. WARNING: A qualified service person must In the absence of local codes, use the latest edition of The install appliance. Follow all local codes. National Fuel Gas Code, ANSI Z223.1/NFPA 54*. *Available from: NOTICE: State or local codes may only allow American National Standards Institute, Inc. - Page 5 INSTALLATION Continued MINIMUM FIREPLACE CLEARANCE TO COMBUSTIBLE Minimum Noncombustible Material Clearances MATERIALS If Not Using Mantel Side Wall 16", Ceiling 42" NOTE: If using a mantel proceed to If Using Mantel. If not Floor 5", Front: 36" using a mantel, follow these instructions. You must have noncombustible material(s) above the fireplace LOG SIZING REQUIREMENTS opening.
- Page 6 INSTALLATION Continued MANTEL CLEARANCES NOTICE: Surface temperatures of adjacent In addition to meeting noncombustible material clearances, walls and mantels become hot during opera- you must also meet required clearances between fireplace tion. Walls and mantels above the firebox may opening and mantel shelf. If you do not meet the clearances become hot to the touch.
- Page 7 INSTALLATION Continued For Massachusetts Residents Only: Installation of this gas Chimney Height - Minimum Permanent Flue Opening log set as a vented indoor appliance in the Commonwealth of 6' to 15' 39 sq. inches Massachusetts requires the damper be permanently removed 15' to 30' 29 sq.
- Page 8 INSTALLATION Continued Masonry Screw For propane/LP units, the installer must supply an external regulator. The external regulator will reduce incoming gas pressure. You must reduce incoming gas pressure to between 11" and 14" of water. If you do not reduce incoming gas pres- sure, appliance regulator damage could occur.
- Page 9 INSTALLATION Continued 3. Pressurize supply piping system by either opening pro- supply and appliance. Locate sediment trap where trapped pane/LP supply tank valve for propane/LP gas or opening matter is not likely to freeze. A sediment trap traps moisture main gas valve located on or near gas meter for natural and contaminants.
- Page 10 LOG COMPATIBILITY CHART Refractory Concrete Logs Burner System Model For Use With This Burner System SOUTHERNCOMFORT30A/B Gas Meter SOUTHERNCOMFORT36A/B MAGNIFLAMEOD30NE, MAGNIFLAMEOD30PE SHADYHOLLOW30A/B SHADYHOLLOW36A/B Figure 16 - MF Series Burner System- Log Compatibility Chart Control Valve Location INSTALLING LOGS AND VOLCANIC STONE...
- Page 11 INSTALLATION Continued Right Front Log (D-061, D-019 or D027) Burner Tube Grate Finger Figure 17 - Installing Right Front Log Round Tube Burner Figure 17C - Installing Right Front Log, Side View 2. Find the back left log (SouthernComfort24 and ShadyHollow24 inch models: D-060 or SouthernComfort30 a n d S h a d y H o l l o w 3 0 i n c h m o d e l s : D - 0 1 8 o r SouthernComfort36 and ShadyHollow36 inch models:...
- Page 12 INSTALLATION Continued Log Notch Burner Tube Figure 18A - Installing Back Left Log Figure 19A - Installing Front Left Log Side View Vertical Portion of Burner Tube Grate Finger Log Slot Figure 18B - Installing Back Left Log (D-018) Rear View 3.
- Page 13 INSTALLATION Continued Burner Tube Log Notch Figure 20A - Installing Charred Log Top View Square Grate Log Notch Figure 21A - Installing Middle Split Log Rear Top Side View 6. Find the right split crossover log (D-022) The bottom of the log has a rectangular stand off that fits in the slots on the right side of the front right log and the middle split log.
-
Page 14: Operation
INSTALLATION OPERATION Continued FOR YOUR SAFETY 8. Find the back top log (SouthernComfort30 and Shady- READ BEFORE LIGHTING Hollow30 inch models: D-023 or SouthernComfort36 and ShadyHollow36 inch models: D-029).See Figures 24, and WARNING: If you do not follow these instruc- 24A. -
Page 15: Inspecting Burners
OPERATION INSPECTING BURNERS Continued Check burner flame patterns often. IGNITER ASSEMBLY The igniter assembly is factory preset for proper ignition of Incoming the burner. Alterations may have occurred during shipping Gas Line Equipment and handling. Call a qualified service person to readjust the Shutoff Valve igniter assembly if necessary. -
Page 16: Cleaning And Maintenance
Clean these air inlet holes prior to each heating season. Blocked air holes will create soot. We recommend that you clean the unit every three MAGNIFLAMEOD30NE months during operation and have appliance inspected yearly • Rating (Variable): 29,000/40,000 Btu/Hr by a qualified service person. -
Page 17: Wiring Diagram
WIRING DIAGRAM Green Orange White Orange Igniter HI/LO Pilot Solenoid Black AF-4000 AF-5000MOD Main Control Module AF-4000B/P Orange Black Brown Black Black (GND) Brown Brown These wires are not Option used on this application Black Battery Astria.us.com 900635-00A... -
Page 18: Troubleshooting
TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair appliance. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ''ON'' button on remote con- 1. - Page 19 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Delayed ignition of burner 1. Manifold pressure is too low 1. Contact local natural or propane/ LP gas company 2. Burner orifice clogged 2. Clean burner (see Cleaning and Maintenance, Page 16) or replace burner orifice(s) Burner backfiring during combus- 1.
- Page 20 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instruc- tions.
-
Page 21: Accessories
ACCESSORIES Purchase these appliance accessories from your local dealer. If they DAMPER CLAMP can not supply these accessories, contact IHP at Astria.US.com for Cat. No. F1760, Model GA6080 referral information. You can also write to the address listed on For all models. Permanently opens chimney flue damper for vented the back Page of this manual. -
Page 22: Parts
PARTS MODELS MAGNIFLAMEOD30NE AND MAGNIFLAMEOD30PE Cat. No. Model F0561 MAGNIFLAMEOD30NE F0563 MAGNIFLAMEOD30PE Astria.us.com 900635-00A... - Page 23 PARTS MODELS MAGNIFLAMEOD30NE AND MAGNIFLAMEOD30PE This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replace- ment Parts on Page 21 of this manual. CAT. NO. DESCRIPTION QTY. J7992 Burner Stainless MF •...
- Page 24 PARTS LOG SET MODELS SOUTHERNCOMFORT30A/B AND SOUTHERNCOMFORT36A/B This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on Page 21 of this manual. SouthernComfort30A/B SouthernComfort36A/B PART NO. LOG ID NO. PART NO. LOG ID NO.
- Page 25 PARTS LOG SET MODELS SHADYHOLLOW30A/B, AND SHADYHOLLOW36A/B This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on Page 21 of this manual. ShadyHollow30A/B ShadyHollow36A/B CAT. NO. Log Id. # CAT. NO. Log Id.
- Page 26 _____________________________________________________ NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ Astria.us.com 900635-00A...
-
Page 27: Warranty
Innovative Hearth Products Astria Brand Gas Log Set & Outdoor Gas Fire Pit ® Limited Three Year Warranty THE WARRANTY Innovative Hearth Products Limited Three Year Warranty ("IHP") warrants your Astria ® brand Gas Log Set or Outdoor Gas Fire Pit ("Product") to be free from defects in materials and workmanship at the time of manufacture. - Page 28 Astria.us.com Record the following important information about your appliance: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name IHP reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
