- Page 1 100 Series Mini Turret Analog Surveillance Camera Installation & Operation Manual...
-
Page 2: Installation
Luma 100 Series Mini Turret Camera Installation Before you start, ensure that the device is in good condition and all the assembly parts are included. Make sure that all equipment is powered off during installation. Ensure the wall is strong enough to hold three times the weight of the camera and the mount. -
Page 3: Box Contents
Luma 100 Series Mini Turret Camera Box Contents Camera Mounting bracket Self-adhesive mounting template 3 x wall anchors with screws 3mm hex wrench Other Required Equipment Aside from the contents of this box, you will need Phillips screwdriver Power source: 12V DC... - Page 4 Luma 100 Series Mini Turret Camera Overview Before installing, familiarize yourself with the parts of your camera. Camera Body...
- Page 5 Luma 100 Series Mini Turret Camera Camera Base Cables The camera comes with two cables: the black BNC cord is the video cable, and the red-capped cord is the power cable.
-
Page 6: Prepare For Installation
Luma 100 Series Mini Turret Camera Prepare for Installation 1. Drill a cable hole and pilot holes for your screws in the ceiling, using the supplied template shown. - Page 7 Luma 100 Series Mini Turret Camera 2. Loosen the locking hex screw on the base and remove it from the camera housing. Locking Hex Screw...
-
Page 8: Install The Camera
Luma 100 Series Mini Turret Camera Install the Camera 3. Attach the base of the camera to the ceiling and secure it with screws. 4. Route the cables through the cable hole. Note that the base provides extra space between the camera and the ceiling for wire management. - Page 9 Luma 100 Series Mini Turret Camera 5. Insert the camera into the base. Ensure the open area of the housing is pointed in the direction you want the camera to aim. Tighten the locking hex screw to secure the camera in place.
- Page 10 Luma 100 Series Mini Turret Camera 6. Connect the power and video cables and power up the camera.
-
Page 11: Adjust The Camera
Luma 100 Series Mini Turret Camera Adjust the Camera 1. Manually adjust the camera to get an optimum angle, being careful not to touch the lens. The camera is free-floating for perfect pan and tilt control. - Page 12 (RA) number. Contact technical support for an RA number. Copyright ©2015 by SnapAV. All rights reserved. SnapAV, Luma Surveillance, and all related marks and images are trademarks or registered trademarks of SnapAV. Version 150902-1151...
