Use a tissue, lightly moistened with alcohol or a hospital-grade cleanser such as Sporicidin –
(Do not saturate) - wipe off debris, dirt or other matter that may gather on either the Handset
or Pendant of the ​ T ele ​ P atch System. If the Pendant has been dropped in a basin of water (i.e.:
sink or toilet) and will not power back on, contact Customer Support for a replacement.
Pendant Action
Pendant power up
Pendant ready to start
procedure
Procedure initiated: Press
Symptom button 3 times
(Holter Only)
Procedure initiated not in
cradle: Press Symptom
button 3 times (Holter
procedure only)
Procedure in progress: not in
cradle
Pendant removed from
Cradle
Pendant placed in cradle with
procedure running BT
OFF/Holter
Symptom Button Press on
cables or patch: Record
Symptom
Tele ​ P atch™ ​ C ardiac Monitor PM750
USER MANUAL - UTM0000701-05E ​
61
8 77-996-5553

VISUAL AND AUDIBLE INDICATORS

Normal Performance Indicators

Visual Indicator
Green, blue, and orange lit
simultaneously for 1.5 seconds.
Green LED blinks fast
Green LED solid for 1.5 seconds
Orange and blue blinks fast in
unison
3 LED sections: continuous
flashing
3 LED sections: continuous
flashing
Green LED: every 4 seconds
Green LED lit for 1 second
| APRIL 4, 2019
Audible Indicator
Beep High-Low-High for 0.5
second per frequency while
LEDs are lit.
None
Beep High-Low-High for 0.5
second duration for each
beep
Beep 4 times in unison with
LEDs
None
None
Beep for 2 seconds before
entering this mode for the
first time
Beep for 1 second
