LG Handset
The port for the LG Charger Cord is located on the bottom side of the Handset.
Charger properly inserted
Correct direction of charger head
Incorrect direction of charger head
Connecting the Charger Cord to the Handset:
Take the end of the Charger Cord and insert it into the lower left side or bottom of the Handset
as displayed in the graphic above according to the handset manufacturer. The side of the
Charger Cord plug-in with the engaging teeth facing down is the correct way to insert the
Charger Cord into the Handset.
WHEN CHARGING IS COMPLETE, UNPLUG THE CHARGER CORD FROM THE POWER
OUTLET AND THE Handset.
MAKE SURE WALL OUTLET IS NOT CONTROLLED BY A LIGHT SWITCH.
