Device Link Capabilities
Slot time
Min. inter PDU delay
Max. response delay
Transducer Blocks
Block Content
Setup Transducer Block Contains all parameters for a standard commissioning
procedure
Advanced Setup Transducer Contains all parameters for a more detailed configuration
Block of the device
Display Transducer Block Contains all parameters for the configuration of the
display module
Diagnostic Transducer Block Contains diagnostic information
Expert Configuration Contains parameters which require detailed knowledge
Transducer Block of the functionalities of the device
Expert Information Contains information about the state of the device
Transducer Block
Service Sensor Transducer Contains parameters which can only be operated by
Block Endress+Hauser service personnel
Service Information Contains information on the state of device which is
Transducer Block relevant for service operations
Data Transfer Transducer Contains parameters which allow to backup the device
Block configuration in the display module and to restore it into
the device.
1) depending on the configuration of the block
Function Blocks
Block Content
Resource Block The Resource Block contains all the data
that uniquely identifies the field device.
It is an electronic version of a nameplate
of the device.
Analog Input The AI block takes the manufacturer's
Block input data, selected by channel number,
and makes it available to other function
blocks at its output.
Discrete Input The DI block takes a discrete input value
Block (e.g. indication of an level limit), and
makes it available to other function
blocks at its output.
PID Block The PID block serves as proportional-
integralderivative controller and is used
almost universally to do closed-loop-
control in the field including cascade and
feedforward.
Arithmetic This block is designed to permit simple
Block use of popular measurement math
functions. The user does not have to
know how to write equations. The math
algorithm is selected by name, chosen by
the user for the function to be done.
4
8
20
Number of
permanent
blocks
1
2
1
1
1
Levelflex FMP53
Output values
• Level or volume
(Channel 1)
• Distance (Channel 2)
no output values
no output values
no output values
no output values
no output values
no output values
no output values
no output values
Number of Execution Functionality
instantiable time
blocks
0 - enhanced
3 25 ms enhanced
2 20 ms standard
1 25 ms standard
1 25 ms standard
Endress+Hauser
1)
