DP7XX Series PLUS+1® Mobile Machine Displays

Danfoss Assembled Mating Connector Kits

DP7XX mating connector kit and contents
Connectors
M12 5-pin male
M12 8-pin male
Terminal
Deutsch
Crimp tool
16 to 20 AWG
20 to 24 AWG
Locking plug
12-pin Deutsch WM 12S
12-pin connector kit (16 to 20 AWG)
Deutsch DTM06-12SA 12-pin connector
12-pin connector kit (20 to 24 AWG)
Deutsch DTM06-12SA 12-pin connector
Connection-kit DP7XX with camera cable*
* Only valid for DP710 and DP720.

Accessories

Description
Panel mounting kit
USB cable (device only)
USB cable (device and host)
Compact color camera, 12 V
PLUS+1 GUIDE Software Application (includes a single user
licence, Service and Diagnostic tool and a Screen Editor)
L1315553 • Rev DA • Dec 2013
Part numbers
11130712
11130713
10100743
10100744
10100745
10100741
10102025
10100944
11130520
Part number
11144800
11130518
11130519
10100831
10101000
