DP7XX Series PLUS+1® Mobile Machine Displays

Multifunction

Frequency Input Low Range (PPU)
Description
Range
Sensitivity
Low threshold voltage
High threshold voltage
Input impedance
Input impedance with pull-down
Input impedance with pull-up
Input impedance with pull-up/down
Frequency Input Normal Range (PPU)
Description
Range
Range (phase and quad)
Low threshold voltage
High threshold voltage
Input impedance
Input impedance with pull-down
Input impedance with pull-up
Input impedance with pull-up/down
Resistance Input
Description
Range
Resolution
Source current
4–20 mA Input
Description
Range
Resolution
Worst case error
Input impedance
Shut-off current
The displays do not have a Real Time Operating System (RTOS). Because of this the display should not
be used as the master control for any type of safety critical control, or closed loop control system.
Frequency inputs are managed by the operating system. Because of this it should be avoided to use
these inputs for any type of Safety Critical closed loop control as the accuracy maybe affected by
processor load. They should only be used for non-safety critical related functions.
L1315553 • Rev DA • Dec 2013
Unit Minimum Maximum
Hz 0 10000
mVpp 1000 —
mV 75 200
mV 150 350
kΩ 233 ± 3
kΩ 14.1 ± 0.3
kΩ 14.1 ± 0.3
kΩ 7.27 ± 0.2
Unit Minimum Maximum
Hz 0 10000
Hz 0 5000
V 1.1 2.6
V 2.2 4.4
kΩ 233 ± 3
kΩ 14.1 ± 0.3
kΩ 14.1 ± 0.3
kΩ 7.27 ± 0.2
Unit Minimum Maximum
Ω 0 10000
1
2
42
m 0 4
Unit Minimum Maximum
mA 0 50
μA 22
mA ±(0.2 + I*3%)
Ω 100 ± 2
mA 54
Comment
In steps of 1 Hz
Sinus peak-to-peak
—
—
To 0 V
To 0 V
To 5 V
To 2.5 V
Comment
In steps of 1 Hz
When measuring phase or
quadrature counts
—
—
To 0 V
To 0 V
To 5 V
To 2.5 V
Comment
In steps of 1 Ω
@ 0 Ω
@ 1 kΩ
@ 10 kΩ
—
Comment
—
—
—
To 0 V
—
