RIZE B OA R D
™
SE TTI NGS A ND F UNC TI O NS
BATTERY
The 9V b attery will last for ab out 12,0 0 0 shots. Please b e aware that there are sub stantial
d ifferences in p erformance b etween d ifferent b rand s of b atteries. Use of hig h q uality alkaline or
lithium ion b atteries is recommend ed for maximum b attery life. If you p lan not to use your marker
for a long p eriod of time ( a month) , it is recommend ed that you remove the b attery from the
marker. W hen the b attery voltag e starts to g o too low, the marker will not fire with every trig g er
p ull. For tournament use, it is recommend ed to chang e the b attery for each tournament.
CHANGING THE BATTERY
The b attery is housed on the rig ht sid e of the g rip frame. To access the b attery, remove the three
screws hold ing the rig ht sid e g rip p anel d own. Use a 3⁄32" allen key. W hen inserting a new b attery
notice the + and - marks on the b oard . The p ositive lead of the 9V b attery g oes to the left and the
neg ative lead to the rig ht.
NOTE: If the marker will not function with the eye on, there is a good chance the battery needs
to be changed.
• A low battery will not be able to power both the ACE eye and the trigger
switch, causing ACE eye failure.
• If the b attery is low, the marker will not fire with every trig g er p ull.
12
W W W . D Y E P A I N T B A L L . C O M
ADJUSTING YOUR TRIGGER
FIGURE 1
The Trig g er 's forward travel and over travel are fully
ad justab le so that the user can fine- tune the trig g er to
1
his/ her exact p reference.
2
To ad just the trig g er an .0 50 " and 5/ 64 ' A llen key is
need ed . There are two ad justment screws located on the
trig g er.
The up p er screw on the front of the trig g er controls the
forward travel ( 1) and req uires a 5/ 64 " allen wrench to
ad just. Screwing it in will incease the trig g er 's leng th of
p ull. Note: If this screw is screwed too far out, the switch
will b e d ep ressed all the time causing the RIZE ™ to fire
once immed iately after turning it on and not firing after that! ( F ig . 1) .
The lower screw on the front of the trig g er controls the over travel ( 2) and req uires the .0 50 " allen
wrench to ad just. By turning this screw you can ad just how far b ack the trig g er will travel. Note: If
this screw is ad justed too far, the trig g er will not b e allowed to travel far enoug h to d ep ress the
switch and the marker will not fire.
The trig g er sp ring used to return the trig g er is located insid e the frame. It is not sug g ested to
remove this sp ring as it will cause excess wear on the microswitch and cause trig g er b ounce.
• Be sure the trigger is not adjusted to the point where it is too sensitive
and may cause accidental discharge of the marker.
• Removing the trigger spring will cause premature wear on the microswitch,
resulting in failure.
• Be sure you do not pinch the wires between the frame and body when
reattaching the frame to the body.
