  • Page 1 ™...

  • Page 2: Table Of Contents

    O W N E R ’ S M A N U A L TA B L E O F C O N T E N T S QUICK REFERENCE .....................PAGE 02 IMPORTANT SAFETY INSTRUCTIONS AND GUIDELINES .

  • Page 3: Quick Reference

    QUICK REFERENCE USING YOUR MARKER W A R N I N G Air Supply - The M7 should be operated using air/nitrogen gas only. This air needs to be supplied to the Hyper2™ in-line regulator at a I M P O R T A N T S A F E T Y I N S T R U C T I O N S A N D G U I D E L I N E S regulated pressure of no more than 850 psi.
  • Page 4 M7 BOARD M7 BOARD SETTINGS AND FUNCTIONS SETTINGS AND FUNCTIONS BUTTONS AND LED INDICATOR YELLOW – RATE OF FIRE (VALUES 1-20) There are two buttons and a LED indicator mounted inside the frame of the M7. These are accessible on the back side of the frame. The top The ROF setting is used the set the maximum rate of fire of the M7.

  • Page 5: Trigger Adjustment

    M7 BOARD TRIGGER ADJUSTMENT SETTINGS AND FUNCTIONS AND ON/OFF AIRPORT BATTERY Figure 1 ADJUSTING YOUR TRIGGER The 9V battery will last for about 40,000 shots. Please be aware that there are substantial differences in performance between different brands of batteries. Use of The trigger’s forward travel and over travel are fully adjustable so that the user can fine-tune high quality alkaline or lithium ion batteries is recommended for maximum battery life.

  • Page 6: Fuse Bolt

    FUSE™ BOLT FUSE™ BOLT ASSEMBLY AND MAINTENANCE ASSEMBLY AND MAINTENANCE BOLT MAINTENANCE Regular M7 Fuse™ bolt maintenance is vital to the performance of the M7. If the Fuse™ bolt is not kept well-greased and the o-rings in good shape, the performance of the M7 will be greatly hindered. FUSE™...
  • Page 7 LPR (LOW PRESSURE REGULATOR) LPR (LOW PRESSURE REGULATOR) ADJUSTMENTS AND MAINTENANCE ADJUSTMENTS AND MAINTENANCE CHANGING THE SEAL RETAINER Screw out LPR cap in front of the marker using a 1/4” Allen wrench. Screw out LPR seal assembly (brass) using a 3/16” Allen wrench. Screw in new LPR seal assembly.

  • Page 8: Anti Chop Eyes/ Ball Detents

    HYPER2™ IN-LINE REGULATOR ANTI CHOP EYES/ BALL DETENTS ADJUSTMENTS AND MAINTENANCE MAINTENANCE AND CHANGING ANTI CHOP EYES The Anti Chop Eye (ACE) system will prevent the M7 from chopping paint by not allowing the marker to fire until a ball is fully seated in front of the bolt. USAGE The eyes use a beam across the breech.

  • Page 9: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE • If above doesn’t help, remove the frame from the M7 and remove the solenoid • Re-assemble and test. If problems persist, contact authorized service center AIR LEAKS by unscrewing the two screws mounting it down. Apply some lube to the seat for board replacement.

  • Page 10: Parts Kit

    M7 EXPLODED VIEW M7 WARRANTY INFORMATION Warranty and legal information PARTS LIST WARRANTY DYE Precision, Inc. Warrants for one year to the initial retail purchaser, from the initial date of purchase, that the paintball marker and regulator are free from defects in materials and workmanship, subject to the requirements, disclaimers and limitations of this warranty.
  • Page 11 P +886-3-312-6540 F +886-3-311-8723 www.protopaintball.com www.dyematrix.com Copyright ©2006 DYE Precision, Inc. The stylized “proto” logo and the “P” logo are either registered trademarks, trademarks, or design trademarks of DYE Precision, Inc. Dye Precision, Inc. U.S. Patent # 5,613,483 and additional patents pending.
