TDE Instruments Digalox DPM72-MPP Instruction Manual

Graphical panel meter with rgb backlight for analogue signal 0/2 - 10 v and 0/4 - 20 ma
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Package contents:
1. Safety instructions
• Read instruction manual carefully before operating the device! Keep for later
reference.
• Mounting and installation must be carried out by suitably qualified and competent
persons only.
• When working on the device hazardous voltages must not be connected to
the device! The terminals J1-J12 are not isolated from the measuring
circuit.
• The device must not be used as the only protective device or protective
shutdown.
• The device is not intended to protect persons or facilities against harm. Specific
devices must be used to guarantee safety (protection relays, cut-off switches,
etc.).
• When connecting switches to the terminals J1-J6, only switches must be used
whose isolation voltage is at least twice the maximum occurring measurement
voltage. For example, when measuring 30 V DC switches must be isolated for at
least 60 V.
• Do not open the housing!
• Do not use the device in the presence of explosive or flammable substances!
• All cables carrying hazardous voltages must be secured with external separators.
2. Meaning of symbols
General warning sign
(Attention, observe the documentation!)
Warning of an electrical hazard
Digalox DPM72-MPP
Instruction manual (Rev-2019-04)
Graphical panel meter with RGB backlight
for analogue signal 0/2 - 10 V and 0/4 - 20 mA
Panel meter Digalox DPM72-MPP, mounting bracket,
5 jumpers, 2 instruction manuals (EN + DE)
----- 1 / 8 -----

Advertisement

loading
Need help?

Need help?

Do you have a question about the Digalox DPM72-MPP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TDE Instruments Digalox DPM72-MPP

Summary of Contents for TDE Instruments Digalox DPM72-MPP

  • Page 1 Graphical panel meter with RGB backlight for analogue signal 0/2 - 10 V and 0/4 - 20 mA Package contents: Panel meter Digalox DPM72-MPP, mounting bracket, 5 jumpers, 2 instruction manuals (EN + DE) 1. Safety instructions • Read instruction manual carefully before operating the device! Keep for later reference.
  • Page 2 3. Intended use • Indoor use non condensing, non corrosive. • Panel mounting. • Failure to comply with these instructions will void all guarantee and warranty. • In operation, supply the device preferably via screw terminals with 12 to 24 V AC/DC.

  • Page 3: Product Overview

    12 - 24 V Outputs max. historic data display, min/max 30 V 50 mA display, auto-scaling, measurement mode Digalox DPM72-MPP www.digalox.com Made in Germany 3 Supply voltage input 4 USB interface high high 5 Measurement inputs 100 mA max.
  • Page 4 7. Electrical connections Supply 10 V analogue signal 12 - 24 V Fuse 250 mA high high max. 30 V − Digalox Supply 10 V 20 mA analogue signal 20 mA and 10 V analogue signal high high high high max.

  • Page 5: Measurement Mode Selection

    8. Configuration The device can be configured via jumpers manually or with the corresponding software “Digalox Manager” via USB interface. When configuring via jumpers the basic settings can be made independently of a PC. The configuration with the software “Digalox Manager” allows full functionality. Configuration via jumpers A measurement mode can be selected by setting jumpers at J4-J6 according to the table “Measurement mode”.
  • Page 6 9. Other settings The following functions can be activated independently during operation by short- circuiting connectors J1-J3, e.g. using a jumper or switch: J1: Graphical historic data display To activate the graphical historic data display connector J1 is shorted. The unit displays the stored values within the set time base as a graphical trend.

  • Page 7: Specification

    10. Maintenance Periodically check all external cable connections. 11. Cleaning Observe the safety instructions before cleaning the device. Clean the device with a dry lint-free soft cloth. Do not use solvents. 12. Specification DPM72-MPP 12 - 24 V AC/DC ±10% (50/60 Hz ±10%) or via Supply USB (min.
  • Page 8 77.5 58.2 68.0 Panel cut-out 72.0 73.5 14. Available accessories TDE Instruments Digalox DPM72 gasket EPDM/SBR 15. Contact information TDE Instruments GmbH, Gewerbestraße 8, D-71144 Steinenbronn Phone: +49 7157 20801 E-Mail: info@tde-instruments.de Internet: www.tde-instruments.de, www.digalox.com ----- 8 / 8 -----...
