Assembly Instructions

Use 4 Hex Bolts M6x16, each with Spring washer and Washer,
1
to attach Bases to the bottom of the Column. Tighten the 4
Screws (2 per side).
Use 4 Hex Bolts M6x16, each with Spring washer and Washer,
2
to attach Mounting bracket to the top of the Column. Tighten
the 4 Screws.
Use 4 Screws M6x16, to assemble the TV mounting
3
bracket as following.
Use 4 Hex Bolts M8x16, each with Spring washer and
4
Washer, to attach TV mounting bracket on to the Mounting
bracket. Tighten the 4 Screws.
5
