Parts
Control Box
Dimensions
Retracted: 31.89"
Extended: 70.89"
Specifications
Dynamic Load
Static Load
Speed at Full Load:
Stroke Length:
Retracted Length
Weight:
Input Voltage:
Output Voltage:
Overload Protection:
Duty Cycle:
Color:
IP Grade:
Operational Temperature:
Certification:
Tube Material:
Control Options:
Wireless Remote
Wired Handset
28.98"
0.39"
5.67"
5.55"
7.09"
10%
(2 minutes on, 18 minutes
-5ºC~+20C (23ºF~104ºF)
Powder painted steel tube
Wireless remote/ Wired remote
1.26"
1.97"
2.95"
1.18"
2.95"
m6
130 lbs
150 lbs
1.18"/sec
39"
31.89"
42 lbs
110V~ 60Hz, 86W
24VDC 2A
Yes
off)
Black
IP20
CE and UL
3
