Indoor packaged air-to-water heat pump
Plug & Heat
ready to use heat pump
Quick and easy to install
HomeConnect
equipped with
60
HFC
R410A
USE
The XENEA heat pump has been designed for heating applications in new homes.
It can be connected quickly and easily to any type of heat emitter (underfloor heating, fan coil units, radiators and mixed systems, etc.) thanks to numerous
standard components.
RANGE
The XENEA range consists of 4 single-phase and three-phase models of
6, 8 and 10 kW.
If the heat pump is the only source of heat:
Operation in heating mode up to -20°C/+45°C. A separate
source of heat must be used if outdoor temperatures drop below -20°C.
CONFORMITY
LVD 2006/95/EC
NF C15-100
EMC 2004/108/EC
PED 97/23/EC Category 1
NF EN 60-335
Radio standard EN 300-220
DEEE 2002/96/EC
RoHS 2002/95/EC
HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
control
option
HEATING
30/35 - 40/45
If the heat pump is used to back up a boiler:
Operates down to the balance point (temperature below which the heat
pump can no longer keep up with heating needs). Below this point, the heat
pump and boiler run either alternately (heat pump OR boiler) or at the same
time (heat pump AND boiler).
6 to 10 kW
Heating capacity:
1
Advertisement
Table of Contents
Related Manuals for CIAT Xenea 20H
Summary of Contents for CIAT Xenea 20H
- Page 1 Indoor packaged air-to-water heat pump Plug & Heat ready to use heat pump Quick and easy to install HomeConnect equipped with control 6 to 10 kW Heating capacity: R410A option HEATING 30/35 - 40/45 The XENEA heat pump has been designed for heating applications in new homes. It can be connected quickly and easily to any type of heat emitter (underfloor heating, fan coil units, radiators and mixed systems, etc.) thanks to numerous standard components.
- Page 2 Indoor packaged air-to-water heat pump XeNeA COMPOSITION Casing Built-in hydraulic module Casing in RAL 9016 white lacquered steel 3-speed accelerator pump Casing panel in RAL 9016 matching ABS Differential water pressure switch Rain guard grille in RAL 9001 lacquered panel and bird screen 8 L expansion vessel ...
-
Page 3: Quick Selection
Indoor packaged air-to-water heat pump QUICK SELECTION Xenea 35HT Heating capacity to 7/6°C 30/35°C 6,49 8,46 10,23 10,19 Power input 1,49 2,23 2,65 2,64 4,36 3,79 3,86 3,86 Heating capacity to -7/-8°C */35°C 3,85 5,03 6,00 5,99 Power input 2,21 2,58 2,58 2,39... -
Page 4: Operating Limits
AVAILABLE PRESSURE IN SYSTEM The available pressure curves are given for pure water. Subtract 5 kPa from the available pressures in the case of systems using 40% monopropylene glycol (heating mode). XENEA 20H - 28H XENEA 35 H (T) water flow rate (m water flow rate (m HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A... - Page 5 Indoor packaged air-to-water heat pump NET HEATING CAPACITIES Power input integrating compressor + control + fan + accelerator pump + defrosting cycles Hot water outlet temp. (°C) Outdoor XENEA air temp., °C Pi kW Hc kW Pi kW Hc kW Pi kW Pi kW Hc kW...
-
Page 6: Technical Data
Indoor packaged air-to-water heat pump XeNeA TECHNICAL DATA XENEA 35HT Type hermetic scroll Compressor Quantity Oil capacity 0,74 Refrigerant R410A - Charge 2,35 Type and diameter EC motor turbine Ø500mm EC motor turbine Rotation speed Evaporator Type Coil made of grooved copper tubes with aluminium fins Condenser Brazed plate - Water capacity 0,96... - Page 7 Indoor packaged air-to-water heat pump SCHEMATIC INSTALLATION DIAGRAM - on underfloor heating system Check valve + HomeConnect pressure switch control terminal Outdoor sensor UHS safety thermostat kit Insulated Charging (option) flexible connections (option) Buffer tank (optional) - on comfort units (fan coil units or radiators) HomeConnect Outdoor control terminal...
- Page 8 Indoor packaged air-to-water heat pump XeNeA DIMENSIONS Bear in mind the weight and dimensions given in this section when installing the unit. XENEA 35HT Empty weight (kg) Weight in operation (kg) Position of heat pump wall mounting points Inside, place a waterproof coating BA13, for instance placomarine...
-
Page 9: Pre-Installation Recommendations
Indoor packaged air-to-water heat pump INSTALLATION RECOMMENDATIONS Pre-installation recommendations Leave a space for air return and extraction in an outside wall. If possible, install in a mechanical room, laundry room or garage, protected from the elements and frost, and where the ambient temperature does not exceed -9°C/+ 35°C. If possible, avoid installing the unit near a bedroom. To reduce the condensation produced by the unit, it is preferable to install the XENEA in an unheated room. -
Page 10: Electrical Connections
CIAT recommends taking out an annual maintenance contract with a competent professional body. This document is not legally binding. As part of its policy for continual product improvement, CIAT reserves the right to make any technical modification it considers necessary without prior notice.
