NA 15.15 B
07 - 2015
Instruction manual

Advertisement

Table of Contents
loading

Related Manuals for CIAT CONDENCIAT CL2

Summary of Contents for CIAT CONDENCIAT CL2

  • Page 1 NA 15.15 B 07 - 2015 Instruction manual...
  • Page 2 NA 15.15 B EN - 2...

  • Page 3: Table Of Contents

    CONTENTS PAGE 1 - INTRODUCTION 2 - INCOMING GOODS 3 - IDENTIFICATION OF THE EQUIPMENT 4 - GUARANTEE 5 - SAFETY RECOMMENDATIONS 6 - UNIT LOCATION 7 - WEIGHT AND HANDING 8 - OPERATING LIMITS 9 - TECHNICAL CARACTERISTICS 10 - ELECTRICAL CHARACTERISTICS 11 - DIMENSIONS 12 - INSTALLATION 13 - ElECTRICAL CONNECTIONS...

  • Page 4: Introduction

    1 - INTRODUCTION The standard CONDENCIAT CL2 are outdoor air cooled condensing units equipped with : - Low-noise scroll compressor. - Air cooled condenser - Axial flow fan or fans with speed regulation. All units are factory checked and tested ; they are supplied with a full R 410A refrigerant charge.

  • Page 5: Technical Caracteristics

    9 - TECHNICAL CARACTERISTICS CONDENCIAT CL2 Number SCROLL Type Compressor 1.25 Oil capacity Type of oil R410a Refrigerant 2.65 2.75 Refrigerant weight 45W / 0.2A Crankcase heater 45W / 0.2A Option (1) Power and current Grooved copper tubes - aluminium fins Type of coil Hélicoid...

  • Page 6: Dimensions

    11 - DIMENSIONS Condenciat Models CL2 28 and 35 Anti-vibration Anti-vibration mount spacing mount spacing holes for fixing the Four fixing points mounts to the floor (HM8 x 55 screws) Detail A Position of holes for fixing the anti-vibration mounts to the floor External air flow LIQUID Line...
  • Page 7 Condenciat Models CL2 50, 65 and 75 Anti-vibration Anti-vibration mount spacing mount spacing holes for fixing the Four fixing points mounts to the floor (HM8 x 55 screws) Detail A Position of holes for fixing the anti-vibration mounts to the floor External air flow LIQUID Line SUCTION Gas Line...

  • Page 8: Installation

    12 - INSTALLATION 1035 1000 Minimum 4 mounting points (M8 screws) Min. Installation on loose ground Installation on a concrete basement Concrete pedestals Concrete pedestal There must be no obstacles preventing free air circulation around the air heat exchanger. Follow the minimum distances given above. Avoid prevailing winds.

  • Page 9: Electrical Connections

    13 - ElECTRICAL CONNECTIONS The CONDENCIAT CL2 units are designed in conformity with the low voltage directive and more specifically in compliance with the international standards EN 60335-1, EN 60335-2-40, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3 and EN 61000-6-4. When making the electrical connections, disconnect the unit from the power supply before carrying out any handling work.

  • Page 10: Refrigerant Connections

    15 - REFRIGERANT CONNECTIONS Once the indoor and outdoor units are positioned, the refrigerant connections must be carried out to connect the units. Installation norms must be respected and the pipe lay-out carefully studied, trying to get the smallest distance between both split units and the smallest number of curves as possible.
  • Page 11 - To load R410A, switch power supply ON and start the compressor (closing of the contact on the external control input) Case of CL2 connected to CIAT’s air handling unit : CL2 are preloaded with R410A. Add the load indicated in the user’s guide of the air handling unit and the additionnal...

  • Page 12: Commissioning

    Maintenance work on compressor Regardless of the refrigerant charge in your system, CIAT The compressor is fixed to the platform by 4 screws diameter demands that this check be carried out in order to keep your 8 mm.

  • Page 13: Failures Control And Analysis

    Boite Postale N°14 01/12/14 01350 CULOZ - FRANCE declares that the designated machine below : Désignation : Condenciat CL2 Trademark : CIAT is in accordance with the arrangements of the modified Machines Directive and with the national legislations transposing it.
  • Page 14 20 - GUARANTEE See our general terms of sale. NA 15.15 B EN - 12...
  • Page 16 Tel. : 08 11 65 98 98 - Fax : 08 26 10 13 63 (0,15 € / mn) Non-contractual document. As part of its policy of continual product improvement, CIAT reserves the right to make any technical modifications it feels appropriate without prior notification. Siège social Avenue Jean Falconnier B.P. 14 01350 Culoz - France Tel.
