Function Overview
7
Function Overview
Charging station (EVSE) and electric vehicle (PEV) communicate using the
powerline standard HomePlug GreenPHY™ 1.1 as per ISO/IEC 15118. The
requirements for this are described in ISO/IEC 15118-3. The INSYS Powerline GP
provides the communication connection between the EVSE controller (as per
ISO/IEC 15118-2) and the electric vehicle (PEV). The data stream will be modulated
to the pilot line of the charging cable or the power line as per ISO/IEC 15118-3
here.
The INSYS Powerline GP provides you with the following functions:
Communication via powerline standard HomePlug GreenPHY™
Coupling of the powerline signal to the pilot line
Coupling of the powerline signal to the power line
SLAC protocol as per ISO/IEC 15118-3
