Display and Control Elements
5.1
Meaning of the Display Elements
Description
Status LED (yellow)
Status LED (green)
Link LED
Power LED
Pilot LED
Table 4: Meaning of the LED displays
18
Display
Meaning
LED on
100 MBit/s connection
LED off
No connection or connection with 10 MBit/s
LED on
Connected
LED blinks Data traffic
LED off
Not connected
LED on
Connected to AVLN (AV Logical Network)
LED off
Not connected to AVLN
LED on
Supply voltage available
LED off
No supply voltage
LED on
Powerline signal coupled to pilot line
LED off
Powerline signal coupled to mains line
INSYS Powerline GP
