- Page 1 SENSORS FOR FOOD AND LIFESCIENCE. Operating Manual Relative Turbidity Meter ITM-51 / ITM-51R 30022 / 1.2 / 2019-06-06 / AR / EU ITM-51/ITM-51R...
-
Page 2: Table Of Contents
Operating Manual ITM-51/ITM-51R Table of contents Application / intended use ..............3 Conformity with standards ..............3 Safety instructions .................. 3 Special features / advantages..............4 Options / Accessoires ................4 Installation and Connection ..............4 Mounting position ...................... 4 Hygienic installation requirements ................ -
Page 3: Application / Intended Use
Operating Manual ITM-51/ITM-51R Application / intended use • Relative turbidity measurement of liquid media for mid to high turbidity range (200…300.000 NTU equivalent) • For use in hygienic applications of the food, beverage and pharmaceutical industries • Suitable for CIP/ SIP up to 140 °C for a maximum of 120 minutes •... -
Page 4: Special Features / Advantages
User Interface with small or large display (retrofittable) • Programming adapter MPI-200 (PC-based) • Tool for detaching the signal module • Full featured remote version (see order matrix for ITM-51R) • Pre-assembled PVC cables Installation and Connection Mounting position Mechanical connection / installation notes •... -
Page 5: Hygienic Installation Requirements
Hygienic installation requirements Conditions for hygienic installation according 3A and EHEDG • The ITM-51 / ITM-51R is designed for CIP/SIP cleaning. The sensor can withstand a maximum of 140 °C / 120 min. • The mounting position must guarantee self-draining properties. -
Page 6: Configuration
Operating Manual ITM-51/ITM-51R Not permitted mounting positions using Tri-Clamp Installation from above or below should be avoided with Tri-Clamp. This can lead to incorrect measurements due to air accumulation or deposits. Configuration The ITM-51 relative turbidity meter is set to operate without requiring special adapta- tions. -
Page 7: Settings Using The Mpi-200 Programming Adapter
Operating Manual ITM-51/ITM-51R Sensor (turbidity measurement): The analog output of the sensor for turbidity can be freely configured. Turbidity: Two different turbidity ranges can be set here, independent of each other. The upper range limit can be freely selected. Switching between the both ranges can be done with the A53/I53 signal module while using the digital switching input X3. - Page 8 Operating Manual ITM-51/ITM-51R Connection plug for the MPI-200-F adapter as an intermediate plug be- tween the ITM-51 electronics and the MPI-200 connection 3 (see the next fig- ure). Connection of the MPI-200 programming adapter 1: no function 2: USB port for connecting to a PC...
- Page 9 Operating Manual ITM-51/ITM-51R Further ID codes can be found in the user software. To view these, right-click on "Info" by the pa- rameter name. An info box appears with the respective ID (see graphic below): Because the search number must have 6 digits, an additional digit is always added in front of the five-digit ID (30034 in the graphic above).
- Page 10 Operating Manual ITM-51/ITM-51R Thru Setup Thru Tu.%Solids X-Pnt 08 Setup 013158 Tu.%Solids Y-Pnt 08 Setup 013178 Tu.%Solids Current Loop Signal 1 Signal Selection Setup 330031 X45a I-Out Underrange Limit Setup 330141 X45a I-Out Overrange Limit Setup 330211 X45a I-Out no Media=...
-
Page 11: Settings Using The User Interface
Operating Manual ITM-51/ITM-51R Digital Output Signal Selection Setup 330037 X67 D-Out Function Setup 331114 X67 D-Out Direction Setup 331124 X67 D-Out Inp. Method Setup 331114 X67 D-Out Switch Pt. Setup 331144 X67 D-Out Hysteresis Setup 331254 X67 D-Out ON Delay... -
Page 12: Screen Display
Operating Manual ITM-51/ITM-51R The system is operated using two control buttons to the left and right of the display. These two buttons can be used to navigate through the tree structure of the User Interface to change param- eters. The button functions are as follows:... -
Page 13: Led Configuration
Operating Manual ITM-51/ITM-51R Measured value cur- Value name rently being output at the current output Measurement unit The bottom line is used to display the second output if available. To leave the display mode and create settings on the sensor, press the right button next to the display twice to enter the menu. -
Page 14: Menu Structure User Interface
Operating Manual ITM-51/ITM-51R 6.6.1 Menu structure User Interface Menu Menu Menu Menu Menu QuickSetup QuickSetup QuickSetup QuickSetup QuickSetup Setup Setup Setup Setup Setup ID Search ID Search ID Search ID Search ID Search Calibr. Calibr. Calibr. Calibr. Calibr. R la. -
Page 15: Example For Setting Turbidity 1 Range Without An Id Code
Operating Manual ITM-51/ITM-51R 6.6.2 Example for setting turbidity 1 range without an ID code: Menu Quick Setup Turbidity 1 R la. x.xx %TU Save Data? QuickSetup Unit Turb1 ID: 014030 Setup Unit Turb2 Range Tb.1 No / Yes ID Search Range Tb.1... -
Page 16: Setting Of Customer-Specific Turbidity / %Solids Curve Via Pc Software
Operating Manual ITM-51/ITM-51R 6.6.3 Setting of customer-specific turbidity / %solids curve via PC software After the PC software is started, a customer-specific curve for the turbidity can be entered via the following node: Turbidity Measurement → % solids → (+). Values need to be entered for at least 2 X and Y points. -
Page 17: Installation Of The "Large User Interface" (Lui)
Operating Manual ITM-51/ITM-51R Installation of the “Large User Interface” (LUI) Remove the plastic cover (continue with step 4), or remove the puck with the mounted small display (continue with step 2) Remove the small display Install the puck in the sensor head... -
Page 18: Retrofitting The Display If A Small Display (Sui) Was Already Installed
Operating Manual ITM-51/ITM-51R 7.2 Retrofitting the display if a small display (SUI) was already installed First the puck with the mounted display needs to be removed using the puck puller tool (Fig. 1). To do so, detach the wires from the cable terminal. Then insert the five arms of the puck puller in the plastic tabs of the puck (Fig. -
Page 19: Dimensions
Operating Manual ITM-51/ITM-51R Dimensions ITM-51 with vertical head orientation. Process Connection TriClamp size Varivent size Type Ø A Type Ø A Ø B TC1 / TL1 50,5 mm 66,00 mm 57,00 mm TC2 / TL2 64,00 mm 84,00 mm 75,00 mm... - Page 20 Operating Manual ITM-51/ITM-51R ITM-51 with horizontal head orientation. Process connection...
-
Page 21: Electrical Connection Analog Signal Modules
Operating Manual ITM-51/ITM-51R Electrical Connection Analog Signal Modules 9.1 Terminal Block of A5x Series Power Supply + Power Supply - Not assigned Digital Input X3 Analog Output X45 + Analog Output X45 - Relay Output 67 Relay Output 67 9.2 Terminal Block of A4x Series... - Page 22 Operating Manual ITM-51/ITM-51R 9.4 M12 Connector of A5x Series Electrical Connection „N“ M12 Connector Signal Module Connector Analog Output X45 + Relay Output X67 Relay Output X67 Analog Output X45 - Power Supply + Not assigned Not assigned Power Supply -...
-
Page 23: Electrical Connection Digital Signal Modules
Operating Manual ITM-51/ITM-51R Electrical Connection Digital Signal Modules 10.1 Terminal Block of I5x Series Power Supply + Power Supply - IO-Link / IO-Link Digital Input X3 Analog Output X45 + Analog Output X45 - Relay Output 67 Relay Output 67 10.2 Terminal Block of I4x Series... - Page 24 Operating Manual ITM-51/ITM-51R 10.4 M12 Connector of I5x Series Electrical Connection „R“ M12 connector Signal Module Connector Analog Output X45 + Relay Output X67 Relay Output X67 Analog Output X45 - Power Supply + Power Supply - IO-Link / IO-Link Digital Input X3 10.5 M12 Connector of I4x Series...
-
Page 25: Itm-51 Io-Link Device Identity
Operating Manual ITM-51/ITM-51R ITM-51 IO-Link Device Identity ITM-51 IO-Link Process Data... -
Page 26: Repair And Maintenance
Operating Manual ITM-51/ITM-51R Repair and maintenance The turbidity sensor described here is maintenance-free. However, it is recommended to check the calibration of the turbidity sensor once a year. For this check the ITM-51-CU calibration check tool is recommended. Ceramic reference... -
Page 27: Technical Data
Operating Manual ITM-51/ITM-51R Technical data Measurement cate- The measurement cate- %TU, NTU, EBC, %solids (customized) gory gory can be selected Measurement range The measurement range 0…300.000 NTU equivalent is freely adjustable 0…200 %TU 0…75.000 EBC Process connection CLEANadapt G1/2" hygienic Tri-Clamp 1.5", 2", 2.5", 3"... - Page 28 Operating Manual ITM-51/ITM-51R Protection class IP 69K Output Analog 1x analog output 4...20 mA, potential- free, 1x relay output potential-free 1x digital input (24 V DC), short-circuit proof Digital IO-Link v1.1 Weight 750 g Negele Messtechnik GmbH | Raiffeisenweg 7 | 87743 Egg an der Guenz | Germany | Phone: +49 83 33 . 92 04 – 0 | Fax: +49 83 33 . 92 04 - 49...
