- Page 1 SENSORS FOR FOOD AND LIFESCIENCE. Operating Manual Inductive Conductivity Meter ILM-4 / ILM-4R 30012 / 3.3 / 2019-04-08 / AR / EU ILM-4 / ILM-4R...
-
Page 2: Table Of Contents
Operating Manual ILM-4 Table of contents Table of contents ....................2 Application / Intended use ..............3 Conformity with standards ..............3 Safety instructions .................. 3 Special features / advantages..............4 Options / Accessories ................4 Installation and Connection ..............4 Mechanical installation.................... -
Page 3: Application / Intended Use
Operating Manual ILM-4 Application / Intended use • Inductive measurement of specific conductivity and concentration of fluid media in the range of 0…1000 mS / cm • For use in hygienic applications of the food, beverage, and pharmaceutical industries • Not suitable for use in explosive atmospheres •... -
Page 4: Special Features / Advantages
Operating Manual ILM-4 Special features / advantages • The sensor structure is based on a modular device platform which can be tailored to re- quirements and is easy to exchange if faulty • Wear-free, inductive measurement procedure • In contrast to conductive measurement procedures, there are no problems due to elec- trode deterioration or polarization. -
Page 5: Requirements For Hygienic Installation
Operating Manual ILM-4 Requirements for hygienic installation Conditions for hygienic installation according 3A and EHEDG • The ILM-4 / ITM-4R is designed for CIP/SIP cleaning. The sensor can withstand a maximum of 150 °C / 60 min. • The mounting position must guarantee self-draining properties. - Page 6 Operating Manual ILM-4 Not permitted mounting positions Installation from top or from bottom should be avoided. This can lead to incorrect measurement due to accumulation of air or deposits. Disregarded flow direction The device should be aligned so that the "FLOW" label on the bottom of the de- vice in the direction of flow.
- Page 7 Operating Manual ILM-4 The sensor is delivered with the following default settings: Analog Output 1 (X45 on terminals 4 and 5) conductivity 1 with measurement range 0…200 mS/cm Analog Output 2 (X67 on terminals 6 and 7) temperature with measurement range 0…150 °C The parameter list accompanying the sensor contains the sensor settings for output 1 (terminals 4 and 5) under X45a and for output 2 (terminals 6 and 7) under X67.
- Page 8 Operating Manual ILM-4 Concentration: Two predefined ranges for common CIP media (NaOH or HNO3) are available for se- lection. In addition, there is the possibility of entering up to 8 customized media specific points (each for conductivity and concentration). A self-defined range is entered by specifying at least 2 points with values >...
-
Page 9: Settings Using The Mpi-200 Programming Adapter
Operating Manual ILM-4 Electronics (Signaling interface): • Signal selection for the 4…20 mA signal: Selection between conductivity 1 or 2, concentration and temperature • Set value for 4 or 20 mA signal: By default, the lower range limit is used for the 4 mA signal and the upper range limit for the 20 mA signal. - Page 10 Operating Manual ILM-4 After the sensor is connected to the PC and the user software is opened, the following window ap- pears: 1. Information on the current process value 2. Buttons for changing the parameter setting 3. Information on the current source value 4.
- Page 11 Operating Manual ILM-4 List of important ID codes: Access / setup mode Parameter / (set before Search ID- Node / Value name parameter name change is number module made) Display Contrast User Interface 2 Setup 451020 4 Display Backlight 2 Setup 451030 4 Display Screensaver delay time...
-
Page 12: Settings Using The User Interface
Operating Manual ILM-4 Settings using the User Interface The software structure of the User Interface is like the structure of the PC version. The system is operated using two control buttons to the left and right of the display. These two buttons can be used to navigate through the tree structure of the User Interface to change param- eters. - Page 13 ID Search ID Search ID Search ID Search ID Search Calibr. Calibr. Calibr. Calibr. Calibr. R l. R l. R l. R l. Operating Manual ILM-4 Quick Setup Setup ILM-4 Calibration R l. ID-Search Unit Tcomp Sensor OffsetCd 1 TempComp 1 Display Offset Cd C 000000...
-
Page 14: Screen Display
Operating Manual ILM-4 6.4.1 Screen display After the sensor parameters have been adapted/changed, or after the sensor is switched on and no change is made, the sensor shows the current measurement value. By pressing the right button, different measurement values will be shown. After pressing the left button long, the default meas- urement will be displayed. -
Page 15: Examples Of Sensor Settings
Operating Manual ILM-4 6.5 Examples of sensor settings Several examples of settings that can be created on the Simple User Interface or on the user inter- face of the PC follow (setting of a customized conductivity 1, the associated temperature coeffi- cient and the concentration curve). -
Page 16: Example For Setting Conductivity 1 Using The Display
Operating Manual ILM-4 6.5.2 Example for setting conductivity 1 using the display Menu Quick Setup Conducty 1 R l. 0 mS/cm Save Data? QuickSetup TempComp C ID: 013091 Setup TempComp 2 Range Cd 1 No / Yes ID Search Range Cd 1 0200.0 Calibr. -
Page 17: Installation Of The „Large User Interface" (Lui)
Operating Manual ILM-4 Installation of the „Large User Interface“ (LUI) Remove the plastic cover (continue with step 4), or remove the puck with the mounted small display (continue with step 2) Remove the small display Install the puck in the sensor head Mount large display Hot-plug function: The large display can be installed while the sensor is energized, but this re- quires the usual precautionary measures when working with electronic components. -
Page 18: Retrofitting The Display If A Small Display (Sui) Was Already Installed
Operating Manual ILM-4 7.2 Retrofitting the display if a small display (SUI) was already installed First the puck with the mounted display needs to be removed using the puck puller tool (Fig. 4). To do so, detach the wires from the cable terminal. Then insert the five arms of the puck puller in the plastic tabs of the puck (Fig. -
Page 19: Dimensions
Operating Manual ILM-4 Dimensions For all process connections, the conductivity sensor can be ordered with a submersion length of L20 (20 mm) or L50 (50 mm). -
Page 20: Electrical Connection Analog Signal Modules
Operating Manual ILM-4 Electrical Connection Analog Signal Modules 9.1 Terminal Block of A5x/A6x Series Power Supply + Power Supply + Power Supply - Power Supply - Not assigned Digital Input X3 Not assigned Digital Input X3 Analog Output X45 + Analog Output X45 + Analog Output X45 - Analog Output X45 -... - Page 21 Operating Manual ILM-4 9.3 M12 connector cables color Anderson Color M12 Connector Standard Color Brown Black White Green Blue Black White Grey 9.4 M12 connectors for A6x/A5x series Electrical connection „N“ M12 connector Signal Module Connector Analog Output X45 + Analog Output X45 + Relay X67 Analog Output X67 +...
- Page 22 Operating Manual ILM-4 9.5 M12 connectors for A4x series M12 connector Signal Module A42 Connector El. Connection „M“ Power Supply + Analog Output X45 + Analog Output X45 - Power Supply - M12 connector Signal Module A42 Connector El. Connection „L“ Power Supply + Power Supply - Analog Output X45 -...
-
Page 23: Electrical Connection Digital Signal Modules
Operating Manual ILM-4 Electrical Connection Digital Signal Modules 10.1 Terminal Block of I5x/I6x Series Power Supply + Power Supply + Power Supply - Power Supply - IO-Link / IO-Link / IO-Link IO-Link Digital Input X3 Digital Input X3 Analog Output X45 + Analog Output X45 + Analog Output X45 - Analog Output X45 -... - Page 24 Operating Manual ILM-4 10.3 M12 connector cables color Anderson Color M12 Connector Standard Color Brown Black White Green Blue Black White Grey 10.4 M12 connectors for I6x/I5x series Electrical connection „R“ M12 connector Signal Module Connector Analog Output X45 + Analog Output X45 + Relay X67 Analog Output X67 +...
-
Page 25: Ilm-4 Io-Link Device Identity
Operating Manual ILM-4 ILM-4 IO-Link Device Identity ILM-4 IO-Link Process Data... -
Page 26: Repair And Maintenance
Operating Manual ILM-4 Repair and maintenance The conductivity sensor described here is maintenance-free. However, if it should become nec- essary to calibrate the sensor, the offset (zero point) and the span of the sensor can be set in the "Calibration " mode (via the software). For this purpose, navigate to the following window via the user interface (for example, for con- ductivity 1): "Conductivity Measurement →... - Page 27 Operating Manual ILM-4 Reproducibility of conductivity < 1% of measurement value Resolution/measure- < 1 mS / cm 0,001 mS / cm ment range < 10 mS/cm 0,01 mS / cm < 100 mS / cm 0,1 mS / cm < 1000 mS / cm 1 mS / cm Accuracy Slope...
- Page 28 Operating Manual ILM-4 Negele Messtechnik GmbH | Raiffeisenweg 7 | 87743 Egg an der Guenz | Germany | Phone: +49 83 33 . 92 04 – 0 | Fax: +49 83 33 . 92 04 - 49 Anderson Instrument Company Inc. | 156 Auriesville Road | Fultonville, NY 12072 | Phone: +1 518-922-5315 | Fax: +1 518-922-8997...
