WolfVision VZ-5D Instructions

Technical data:
Built-in camera system:
Effective pixels:
Horizontal resolution:
Iris:
Autofocus:
White balance:
Optics (5,4 – 64,8mm, f=1,8~2,7):
Depth of focus 14mm (0,6") on smallest picture, size: 16x12m m (0,6"x0,5")
(depth of field): 18mm (0,7") on small pict ure, size: 42x33mm (1,7" x1,3")
200mm (8") on largest pi cture, size: 360 x270mm (14,4"x10,8")
Camera control panel:
Power and light control s:
Power-on preset:
Light source:
Light system: light either on working surface or in front of the unit, no blinding of
Objects on working surfac e
(length x wi d th):
Objects on working surfac e (height): up to 370mm (15") in wi de position - 110mm (4,4") in tele position
Objects in a room:
4-pin connector, Y -signal: 1 Vpp 75Ω, C-signal: 0,3 Vpp 75 Ω
Y/C (S-video) output:
Composite video output:
12 V DC output:
Power consumption:
Power source:
Made in:
Weight:
Accessories (Scope of s upply):
Mains power pack:
Carrying case (Soft case)
Other supplied accessori es:
Specifications and availability subject to change
235mm (9.2")
405 mm (15.9")
150mm (5.9")
405 mm (15.9")
CONTACTS :
Manufacturer: Wolf Vision GmbH, Vlbg. Wirtschaftspark, A-6840 Götzis / AUSTRIA, Tel. ++43-5523-52250,
Fax. ++43-5523-52249, E-Mail: wolfvision@wolfvision.com
American distribution: Wolf Vision Inc., 655 Sky Way, Suite 119, San Carlos, CA 94070 / USA
Tel. (650)802-0786 and 1-800-356WOLF , Fax: (650)802-0788, E-Mail: wolfvision.usa@wolfvision.com
Asian representation: WolfVision Rep office, 27 Woodlands Ind. Park E1, #01-04 Hiang Kie Ind. Bldg. IV,
Singapore 757718 / Tel. ++65 - 366 9288, Fax: ++65 - 366 9280, E-mail: info@wolfvisionasia.com
Internet Homepage: http://www.wolfvision.com, Technical support by E-mail: support@wolfvision.com
Made in: Austria (EC)
1 CCD unit – 1/3" interline transf er
PAL models: 752x582 / N TSC models: 768x494
> 470 TV lines
automatic
dynamic high speed, on/ off switch
automatic
24x zoom (12x optical + 2 x digital)
functions: zoom in, zoom out, autofocus on/off
power on/off, light on/of f or light on lightbox
autofocus on, autoiris on, pick -up size: 210x140mm
high frequency fluorescent l amp
audience or speaker, ver y low stray light
min.: 16x12mm (0,6"x0,5" ),
max:360x270mm (14,4" x10,8")
length, width, and height to infinity
RCA-connector, VBS 1,0 Vpp 75Ω
for external lightbox or LCD -monitor
max. 25 VA
12 V DC
Austria (European Comm unity)
Visualizer: 4,6kg (10lbs ), Power pack: 0,7kg (1,1l bs)
90 – 240 V AC / 12 V DC, 1,5 A
included (standard editi on)
Y/C (S-video) cable, instructi ons
Changing the lamp of the
Visualizer:
1. Remove the power cord of
the Visualizer.
2. Remove lamp housing glass.
(1 Screw)
3. Remove the safety clip
4. Change the lamp.
CAUTION: Hot when used!
Lamp type: Osram Dulux S/E
9W/21 or equivalent
Printed in Austria November 2001
PRECAUTIONS
WARNING! To reduce the risk of electric shock, do not open the unit.
No userserviceable parts inside. Refer servicing to
Risk of electric
qualified service personal only.
shock - Dangerous
To reduce the risk of electric shock, do not expose this
voltage inside
appliance to rain or moisture
This product is built according to Directive EMC and to Directive electrical equipment.
Proofments according to UL 1950. CSA - C 22.2 No. 950-95
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
U L
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
®
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
FCC interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
R
Instructions
VZ-5D
English
