Maintenance kits

When you maintain this Edwards product, we recommend you use only Edwards maintenance and service kits.
The maintenance kits available for the RV pumps are listed in
Table 2
Cross Description
Reference
1 Clean and overhaul kit (standard)
2 RV3 blade kit
3 RV5 blade kit
4 RV8 blade kit
5 RV12 blade kit
6 RV3 cartridge kit
7 RV5 cartridge kit
8 RV8 cartridge kit
9 RV12 cartridge kit
10 Inlet-valve kit
11 Motor starting relay kit
12 Outer shaft-seal kit
13 Rotor sleeve kit
*
14 RV3/RV5 motor kit (Europe/USA)
50/60 Hz, 250/300 W, 1 phase 110-120/220-240 V
*
15 RV8/RV12 motor kit (Europe/USA)
50/60 Hz, 450/550 W, 1 phase 110-120/220-240 V
*
16 RV3/RV5 motor kit (Japan)
50/60 Hz, 250/300 W, 1 phase 100/200 V
*
17 RV8/RV12 motor kit (Japan)
50/60 Hz, 450/550 W, 1 phase 100/200 V
18 RV3/RV5 motor kit (Europe/USA/Japan)
50/60 Hz, 250/300 W, 3 phase 200-230/380-460 V
19 RV8/RV12 motor kit (Europe/USA/Japan)
50/60 Hz, 450/550 W, 3 phase 200-230/380-460 V
20 Oil pump kit RV3/RV5/RV8/RV12
21 Clean and overhaul kit (Nitrile)
22 RV3/RV5/RV8 and RV12 Motor kit (Europe/USA) 50/60 Hz,
450/550 W, 1-phase 220-240/ 230-240 V
23 RV3/RV5/RV8 and RV12 Motor kit (Japan) 50/60 Hz, 450/
550 W, 1-phase 100-200/ 200-210 V
24 RV voltage switch kit
25 RV 3-phase voltage switch set
26 Voltage label-200V-small pk 10
*
As of the end of 2010 the four RV 1-phase motors (used in kits 14, 15, 16 and 17) have been made obsolete
and replaced by two new motors (items 401). These are supplied in kits 22 and 23.
© Edwards Limited 2018. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Table 2
Table 2 - Maintenance kits
A652-01-840 Issue P
below:
Item Number
Hydrocarbon
A652-01-131
A652-01-130
A653-01-130
A654-01-130
A655-01-130
A652-01-032
A653-01-032
A654-01-032
A655-01-032
A652-01-036
A505-74-000
A652-01-134
A652-01-136
A652-99-000
A654-99-000
A652-98-000
A654-98-000
A652-97-000
A654-97-000
A652-01-805
A652-01-137
A652-99-500
A652-98-500
NXC7-56-001
A210-01-981
A200-02-776
PFPE Variants
A652-01-131
A652-01-130
A653-01-130
A654-01-130
A655-01-130
A652-09-032
A653-09-032
A654-09-032
A655-09-032
A652-01-036
A505-74-000
A652-01-134
A652-09-136
A652-99-000
A654-99-000
A652-98-000
A654-98-000
A652-97-000
A654-97-000
A652-01-805
A652-99-500
A652-98-500
NXC7-56-001
A210-01-981
A200-02-776
