Technical description
Chapter 6
PA 7400
More information:
Additional information like the identifier string (e.g.: PCI1500-50) or the
installed COM interfaces.
Text boxes:
Under the table you will find 6 text boxes in which you can change the
parameters of the board.
Base address name:
When the board operates with several base addresses (One for port 1, one for
port 2, etc.) you can select which base address is to be changed.
Base address:
In this box you can select the base addresses of your PC board. The free base
addresses are listed. The used base addresses do not appear in this box.
Interrupt name:
When the board must support different interrupt lines (common or single
interrupts), you can select them in this box.
Interrupt:
Selection of the interrupt number which the board uses.
DMA name:
When the board supports 2 DMA channels, you can select which DMA channel
is to be changed.
DMA channel:
Selection of the used DMA channel.
Buttons:
1
Edit
:
Selection of the highlighted board with the different parameters set in the text boxes.
Click on „Edit" to activate the data or click twice on the selected board.
Insert:
When you want to insert a new board, click on „Insert". The following dialog
window appears:
1 "x": keyboard shorcuts; e.g. "Alt + e" for Edit
25
