Ceraphant PTP31B, PTP33B
Overview
A
Endress+Hauser
3

Product description

3.1

Product design

B
D
E
D
E
3.2

Function

3.2.1 Calculating the pressure
Devices with metallic process isolating diaphragm
The process pressure deflects the metal process isolating diaphragm of the sensor and a fill
fluid transfers the pressure to a Wheatstone bridge (semiconductor technology). The
pressure-dependent change in the bridge output voltage is measured and evaluated.
Item
A
C
B
C
A0022015
D
E
A0027215
A0027227
Product description
Description
Valve plug
Cable
M12 plug
Housing cap made of plastic
Housing
Process connection (sample illustration)
