Section 2: General Information

The Generator

R
A
P
O
N
A. Lock with Cover
B. Main Line Circuit
Breaker (Generator
Disconnect)
C. Control Panel
D. Battery Compartment
(Battery not supplied)
E. Exhaust Enclosure
Owner's Manual for 60 Hz Air-Cooled Generators
Q
M
Figure 2-1. 9kW—Components and Control Locations
F. Oil Fill Cap/Dipstick
G. Status LED Indicators
H. Airbox with Air Cleaner
J. Oil Filter
F
B E
C
D
L
K
J
K. Oil Drain Hose
L. Composite Base
M. Sediment Trap
N. Fuel Regulator
General Information
G
H
A
001818
O. Fuel Inlet
P. Wi-Fi Module
Q. Data Decal Location
R. Auxiliary Shutdown
Switch
