Content 1 Preliminary note ���������������������������������������������������������������������������������������������������3 1�1 Symbols used ������������������������������������������������������������������������������������������������3 2 Functions and features ����������������������������������������������������������������������������������������3 3 Installation������������������������������������������������������������������������������������������������������������3 4 Operating and display elements ��������������������������������������������������������������������������4 5 Electrical connection ��������������������������������������������������������������������������������������������4 5�1 PNP ���������������������������������������������������������������������������������������������������������������4 5�2 NPN ���������������������������������������������������������������������������������������������������������������5 6 Setting the range �������������������������������������������������������������������������������������������������5 6�1 Setting the range by means of background and object ���������������������������������5 6�2 Setting the range by means of the background ���������������������������������������������6 6�3 Setting the maximum range ���������������������������������������������������������������������������7 7 IO-Link �����������������������������������������������������������������������������������������������������������������8...
1 Preliminary note 1.1 Symbols used ► Instruction > Reaction, result […] Designation of pushbuttons, buttons or indications → Cross-reference Important note Non-compliance can result in malfunctions or interference� 2 Functions and features The diffuse reflection sensor detects objects and materials without contact and indicates their presence by a switching signal�...
4 Operating and display elements 1: LED yellow - switching output active 2: LED green - operation 5 Electrical connection The unit must be connected by a qualified electrician� ► The national and international regulations for the installation of electrical equipment must be adhered to� ►...
5.2 NPN Cable * Connector M8 3-pin pigtail Connector M8 4-pin pigtail * Core colours: BN = brown, BU = blue, BK = black 6 Setting the range The settings indicated in this chapter only apply to IO-Link capable PNP diffuse reflection sensors� 6.1 Setting the range by means of background and object 1�...
4� Align the diffuse reflection sensor to the background� TP1: teach point 1 TP2: teach point 2 5� Press button [Teach SP1 TP2] in the LR DEVICE software� > The switch point SP1 is between object and background� TP1 SP1 Zone „object recognised“...
2� Align the diffuse reflection sensor to the background� 3� Press button [Teach Custom - SP1 without target] in the LR DEVICE software� > The switch point SP1 is just in front of the background� Zone „object recognised“ 6.3 Setting the maximum range 1�...
In addition communication is possible via a point-to-point connection with a USB adapter cable� You will find more detailed information about IO-Link at www�ifm�com/uk/io-link� 7.2 Device-specific information You will find the IODDs necessary for the configuration of the IO-Link device and detailed information about sensor values, diagnostic information and parameters in the overview table at www�ifm�com/uk/io-link�...
► For cleaning do not use any solvents or cleaning agents which could damage the plastic parts� ► After use dispose of the unit in an environmentally friendly way in accordance with the applicable national regulations� Faulty sensors must only be repaired by the manufacturer� Technical data and further information at www�ifm�com...
