Automatic sliding door operator
Hide thumbs Also See for CS 80 MAGNEO:
Table of Contents

Advertisement

Quick Links

DORMA
CS 80 MAGNEO
CS 80
MAGNEO
Automatic
sliding door operator
Technical
Documentation
Read the manual before
the assembly carefully!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS 80 MAGNEO and is the answer not in the manual?

Questions and answers

Related Manuals for Dorma CS 80 MAGNEO

Summary of Contents for Dorma CS 80 MAGNEO

  • Page 1 DORMA CS 80 MAGNEO CS 80 MAGNEO Automatic sliding door operator Technical Documentation Read the manual before the assembly carefully!
  • Page 2 CS 80 MAGNEO Dear customer, Thank you for buying a product from our product range. The DORMA brand stands for first-class and scrutinised quality products offering extremely high safety standards. This documentation contains important information for the safe installation of the system.

  • Page 3: Table Of Contents

    A remark will call your attention to important information that will facilitate your work with the CS 80 MAGNEO. ADVISE An advice will warn you that you could damage the CS 80 MAGNEO and explain how to avoid this. ATTENTION Here we will inform you of dangers that might cause damage to property or injure or kill people.

  • Page 4: Safety Instructions

    Depending on the structural conditions, the door version and the safety equipment, residual risks cannot be excluded. CS 80 MAGNEO as low-energy product according to German DIN 18650 (German Industrial Standard) According to the German Industrial Standard DIN 18650, the movement range of an automatic door always has to be protected (amongst others) by safety sensors.
  • Page 5 Please keep this documentation for later reference. 1.6 General information regarding the installation of the system The CS 80 MAGNEO must be disconnected from power supply (de-energized) when performing mounting or installation work. Remove the power plug, or, in case of permanent power supply, switch off fuse.
  • Page 6 · This device must not be disposed of as domestic waste. CS 80 MAGNEO - Awarded safety Developed according to the latest safety standards: Low-Energy-Mode in accordance with DIN standard...

  • Page 7: Functional Characteristics

    DORMA CS 80 MAGNEO 2. Functional Characteristics 2.1 General information The speed is infinitely variable with the aid of a potentiometer (located inside the CS 80 MAGNEO is a single-panel operator). electromechanical sliding door operator for The closing cycle always remains in Low- small and light interior doors with an Energy-Mode.
  • Page 8 DORMA CS 80 MAGNEO Express-Function 2.7 Safety sensors The door can be moved manually in ist You can install sensors to detect obstacles. operational direction and there will be no According to DIN 18650, an automatic extra resistance. However, when the...

  • Page 9: Technical Data And Features

    DORMA CS 80 MAGNEO 3. Technical data and features Power supply: Power supply: 220 230 V AC ±10%; 50/60 Hz Fuse protection (by others): 10 A Cable type: max. 3 x 1.5 mm² Power consumption without external accessories: Stand-By-Mode: 3.7 W Automatic-Mode: max.

  • Page 10: System Overview

    DORMA CS 80 MAGNEO 4. System overview Control unit and connection Power supply CS 80 MAGNEO terminals for external accessories Actuated opening direction Control unit and connection terminals for external accessories Potentiometer Connection terminals for DIP switch light indicator hold-open time...

  • Page 11: Before Mounting

    DORMA CS 80 MAGNEO 5. Before mounting Basic requirements: Work on electrical equipment may only be performed by properly qualified staff (electricians). · The floor has to be level. · Glass door panels have to be made of safety glass.
  • Page 12 DORMA CS 80 MAGNEO In order to facilitate the cabling inside 60 mm the operator, all cables should have a length of at least 250 mm. For on-wall mounting: If you want all connection cables that are coming out of the wall not to be seen after...
  • Page 13 DORMA CS 80 MAGNEO Open careful the cover of the control unit housing by levering it out with the tip of a flat-bladed screwdriver. Relax the screws of the connection terminals and remove the internal Schuko-type shockproof socket. Then close the cover of the control unit housing.

  • Page 14: Installation Instructions For On-Wall Mounting

    DORMA CS 80 MAGNEO 6. Installation instructions for on-wall mounting Mounting procedure If there is a door frame, you have to shim the angle brackets with the shim plate (optional). Auxiliary lines for positioning purposes See bottom of this page.
  • Page 15 DORMA CS 80 MAGNEO 1.000 1.125 1.060 1.750 2.000 2.250 Closed position With wooden door panel: = Door panel height + 78 mm With glass clamping rail: = Door panel height + 114 mm Passage width (PW) With DORMA MANET...
  • Page 16 DORMA CS 80 MAGNEO Before drilling the holes, check if there Center line are cables or pipes in the close range of the drill holes. Position the fixing bracket onto the centre line. Ensure that the bottom vertex of the triangle is located exactly on the centre line.
  • Page 17 Calculate the dimension from the floor to the upper edge of the shim plate as follows: Door panel height + 78 mm When using DORMA MANET single-point fixings: Door panel height + 74 mm Align the shim plate so that it is level and mark the drill holes.
  • Page 18 DORMA CS 80 MAGNEO Adhere 3 pieces of felt equally onto the bracket. The openings of the door panel suspension have to point to the front When using MANET fixings, the door panel suspensions have to be unscrewed. Fix the operator below the bracket with...
  • Page 19 DORMA CS 80 MAGNEO Close the cover of the control unit housing. Fix and screw down the cover of the power supply housing. Move the end stop to the end of the channel and screw it down thoroughly (see page 13, picture at the bottom).
  • Page 20 DORMA CS 80 MAGNEO Locate and fix the provided floor guide rail. Please consider the mounting instructions of the floor guide. When adjusting the floor guide you have to make sure that the door panel runs smoothly through the floor guide (does not rub against the floor guide).
  • Page 21 1125 mm operator => max. 300 mm The end stop must not overlap at the outer edge. Fix the DORMA logo in the two drill holes. Insert the end caps into the cover. Depending on the prevailing structural conditions, the end caps can either be cut to length or broke out at the predetermined breaking points.

  • Page 22: Installation Instructions For In-Wall Mounting

    DORMA CS 80 MAGNEO 7. Installation instructions for in-wall mounting A = at least L + 120 mm min. 70 mm min. 50 mm Side with connections Bottom edge of lintel With wooden door panel: = Door panel height + 75 mm...
  • Page 23 DORMA CS 80 MAGNEO Hold the operator in the desired position and mark the end of the operator on the side opposite the connections. Draw a further line at a distance of 43 mm. Then position the fixing bracket at the second line and mark the drill holes.
  • Page 24 DORMA CS 80 MAGNEO Then mark the fixing holes through the holes in the operator. In order to reach all 4 holes, you have to move the carrier. Remove the operator and drill fixing holes with a diameter of 4.2 mm for the supplied sheet metal screws.
  • Page 25 DORMA CS 80 MAGNEO Connection of 230 V permanent power supply Work on electrical equipment may only be performed by properly qualified staff (electricians). Before starting with the installation, make sure that the power supply line is dead (de-energized). Relax the end stop and move it to the centre of the system (see page 12, picture in the middle).
  • Page 26 DORMA CS 80 MAGNEO Move the end stop to the end of the channel. The end stop must not fall out of the operator. Place the door panel inside the door frame. As the door panel is wider than the doorway, you will have to tilt it.
  • Page 27 DORMA CS 80 MAGNEO Relax the screws of the end stop on the side where the connections are and move the door to the desired closed position. Move the end stop next to the door panel and screw down tight (5 Nm).

  • Page 28: Connection Diagrams

    DORMA CS 80 MAGNEO 8. Connection diagrams (Only for properly qualified staff!) In order to facilitate the connection of the wires, the different terminal blocks can be removed with pointed pliers. Connection terminals not assigned Approach in case of a short circuit at the connection terminal 1.

  • Page 29: Cable Channel

    DORMA CS 80 MAGNEO 9. Cable channel The cables for external accessories (sensors, pushbuttons etc.) have to be laid inside a 5 0 m m cable channel as indicated in the picture. 6 m m...

  • Page 30: Connection Of Closing Edge Protection

    DORMA CS 80 MAGNEO 10. Connection of closing edge protection This work may only be performed by properly qualified staff. When testable sensors for the protection of the closing edges are connected, the control unit has to be adjusted to the sensors via the DIP switches.

  • Page 31: Commissioning

    You show a permanent green light. can access the door manually. In order to make the operator ready for The CS 80 MAGNEO is now ready for operation, you have to perform a learning operation. cycle.
  • Page 32 DORMA CS 80 MAGNEO Permanent Open Function via double-click Closing force This function can only be adjusted when a In case the door does not close properly due pushbutton is connected. to the door seals, you can increase the force...

  • Page 33: Operation Instructions

    DORMA CS 80 MAGNEO 12. Operating instructions Opening the door in AUTOMATIC Express-Function Function The door can be moved manually along its operational path without extra resistance. When the system is delivered, the CS 80 MAGNEO is adjusted to AUTOMATIC...
  • Page 34 DORMA CS 80 MAGNEO Closing force Program switch EPS-S3 (optional) In case the door does not close properly due to the door seals, you can increase the force with which the operator presses the door against the seal. AUTOMATIC In order to do so, set DIP switch 7 to "ON"...

  • Page 35: Commisssioning And Maintenance According To Din 18650-2

    · Regular maintenance and inspections have to be performed (at least once a year) under consideration of our specifications for the CS 80 MAGNEO by properly trained staff. · Documentation of the results in accordance with DIN 18650-2 paragraph 5.1-5.4.

  • Page 36: Troubleshooting Instructions

    DORMA CS 80 MAGNEO 11. Troubleshooting instructions Malfunction Possible cause Remedy The door does not No power supply. Switch on mains switch. respond. Loose cable connections. Connect cable connections thoroughly. The green LED light indicator is off. Damaged power cord.
  • Page 37 DORMA CS 80 MAGNEO Malfunction Possible cause Remedy The red LED blinks 4 Testable safety sensors are Check and replace safety sensors times at regular defective. if required. Damaged sensor cable. Check and replace cables if intervals. required. DIP switches 1 to 3 are not set Check settings of DIP switches correctly.

  • Page 38: Manufacturer's Declaration

    DORMA CS 80 MAGNEO Manufacturer's declaration...

  • Page 39: Declaration Of Conformity

    DORMA CS 80 MAGNEO Declaration of conformity...
  • Page 40 DORMA CS 80 MAGNEO Door Control Automatic Glass Fittings and Accessories Security/Time and Access (STA) DORMA GmbH + Co. KG DORMA Platz 1 D-58256 Ennepetal Tel. +49 2333/793-0 Fax +49 2333/793-495 Movable Walls...
