Dorma CS 80 MAGNEO Installation And Maintenance Manual

Dorma CS 80 MAGNEO Installation And Maintenance Manual

Automatic sliding door operator
Hide thumbs Also See for CS 80 MAGNEO:
Table of Contents

Advertisement

Quick Links

Download this manual
CS 80 MAGNEO
Automatic sliding door operator
—
Installation and maintenance manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS 80 MAGNEO and is the answer not in the manual?

Questions and answers

Related Manuals for Dorma CS 80 MAGNEO

Summary of Contents for Dorma CS 80 MAGNEO

  • Page 1 CS 80 MAGNEO Automatic sliding door operator — Installation and maintenance manual...

  • Page 2: Table Of Contents

    CS 80 MAGNEO. ADVISE An advice will warn you that you could damage the CS 80 MAGNEO and explain how to avoid this. ATTENTION Here we will inform you of dangers that might cause damage to property or injure or kill people.

  • Page 3: Technical Data And Features

    CS 80 MAGNEO — Installation and Maintenance Manual 1.Technical data and features Power supply: 115VAC ±10%; 50/60 Hz Branch circuit protection (by others): 15 A Cable type: 14 AWG (12 Max) [max. 3 x 1.5 mm Power consumption without external accessories: Stand-By-Mode: 5.6W...

  • Page 4: Greetings/Required Tools

    After installation and adjustment, the installer’s final responsibility is to properly instruct the owner in the safe use of the door. He must also present the owner with the CS 80 MAGNEO Owner’s Manual and carefully explain how to perform the daily safety check test.

  • Page 5: Important Installation Instructions

    ANSI A156.10 & 156.19 Standards for Power Operated Pedestrian Doors. After installation, the door must be adjusted to conform with DORMA recommendations and all code requirements. Carefully study the requirements in these instructions. After installation and adjustment, the installers final responsibility is to properly instruct the owner in the safe use of the door.

  • Page 6: Safety Instructions

    4.2 Product-specific characteristics The CS 80 MAGNEO is intended for use on interior single-panel sliding doors. The CS 80 MAGNEO is neither suitable for application in escape routes, nor on fire and smoke doors nor on exterior doors. 4.3 Standards, laws, codes and regulations CS 80 MAGNEO is a low energy product and complies with the kinetic force limitations of the ANSI 156.19 Low Energy Standards.
  • Page 7 Installation and Maintenance Manual 4.4 Limitation of liability The CS 80 MAGNEO must only be used according to its specified standard operation. DORMA will not accept any liability for damages resulting from unauthorized modifications, unsafe, or improper installation or use of the CS 80 MAGNEO.
  • Page 8 Within the European Union, this device must not be disposed of as domestic waste. It has to be disposed of at as pecial facility so that it can be recycled. CS 80 MAGNEO - Awarded safety Developed according to the latest safety standards: Low-Energy-Mode in accordance with DIN standard...

  • Page 9: Functional Characteristics

    The door closes automatically. le must be limited. The CS 80 MAGNEO operator moves the sliding panel at a low Permanent Open via double-click speed corresponding to ANSI 156.19 energy.
  • Page 10 CS 80 MAGNEO — Installation and Maintenance Manual Express-Function 5.8 Power failure The door can be moved manually in its In the event of a power failure, the door can driving direction and there will be no extra be opened and closed by hand.

  • Page 11: System Overview

    CS 80 MAGNEO — Installation and Maintenance Manual 6. System Overview Optional Power Cord CS 80 MAGNEO Control unit and connection To reduce the risk of electric shock, this terminals for external accessories equipment has a grounding type plug that has a third (GROUNDING) pin.This plug...

  • Page 12: Before Mounting

    (de-energized) during installation. The power supply line must have the apropriate fuse protection in compliance with electrical codes. Use only copper conductors for permanent connection, or use DORMA’S optional power cord (refer to “For optional power cord connection” below for more details).
  • Page 13 CS 80 MAGNEO — Installation and Maintenance Manual 2.4" In order to facilitate the cabling inside the (60 mm) operator, all cables should have a length of at least 10”. For on-wall mounting If you want all connection cables that are...
  • Page 14 CS 80 MAGNEO — Installation and Maintenance Manual Carefully open the cover of the control unit housing by levering it out with the tip of a flat head screwdriver Loosen the screws of the connection terminals and remove the internal Schuko-type shockproof socket. Then close the cover of the control unit housing.

  • Page 15: Installation Instructions For On-Wall Mounting

    CS 80 MAGNEO — Installation and Maintenance Manual 8. Installation instructions for on-wall mounting Mounting procedure Glass door panels with If there is a door frame, you have MANET single-point fixings to shim the angle brackets with Installation type the shim plate (optional).
  • Page 16 CS 80 MAGNEO — Installation and Maintenance Manual **Dimensions marked (=) are equal.** CENTERED 34.4“ [875] 39.4” [1000] 44.3” [1125] 31.9“ [810] 36.8“ [935] 41.7“ [1060] “Closed” position 68.9“ [1750] 78.7“ [2000] 88.6“ [2250] 22.6“ [575] 27.6“ [700] 32.5“ [825] When using Wooden door panel: X = door panel height + 3” [78 mm]...
  • Page 17 CS 80 MAGNEO — Installation and Maintenance Manual Before drilling any holes, make sure Center line there are no cables and/or pipes in the way. Position the fixing bracket onto the center line. Ensure that the bottom vertex of the triangle is located exactly on the center line.
  • Page 18 Position the shim plate at the reference line. Calculate the dimension from the floor to the upper edge of the shim plate as follows: Door panel height + 3.1” [78 mm] When using DORMA MANET single-point fixings: Door panel height + 2.9” [74 mm] Align the shim plate so that it is level and mark the drill holes.
  • Page 19 CS 80 MAGNEO — Installation and Maintenance Manual Adhere 3 pieces of felt equally onto the bracket. The openings of the door panel suspension have to point to the front Wenn using MANET fixings, the door panel suspensions have to be unscrewed.
  • Page 20 CS 80 MAGNEO — Installation and Maintenance Manual Close the cover of the control unit housing. Fix and screw down the cover of the power supply housing. Move the end stop to the end of the channel and screw it down thoroughly (see page14, picture at the bottom).
  • Page 21 CS 80 MAGNEO — Installation and Maintenance Manual Locate and fix the provided floor guide rail. Please refer to the mounting instructions of the floor guide. When adjusting the floor guide you have to make sure that the door panel runs smoothly through the floor guide (does not rub against the floor guide).
  • Page 22 34.4” [875 mm] operator=>7.9” [200 mm] max. 39.4” [1000 mm] operator => 9.5” [250 mm] max. 48.2” [1125 mm] operator => 11.8” [300 mm] max. Fix the DORMA logo in the two drill holes. Insert the end caps into the cover. Depending on the prevailing structural...

  • Page 23: Installation Instructions For In-Wall Mounting

    CS 80 MAGNEO — Installation and Maintenance Manual 9. Installation instructions for in-wall mounting The CS 80 MAGNEO sliding door operator is 2" [50 mm] also suitable for an “invisible” in-wall moun- ting. For this kind of mounting a recess with a width of at least 2”...
  • Page 24 CS 80 MAGNEO — Installation and Maintenance Manual Hold the operator in the desired position and mark the end of the operator on the side opposite the connections. Draw a further line at a distance of 1.7” [43 mm]. Then position the fixing bracket at the second line and mark the drill holes.
  • Page 25 CS 80 MAGNEO — Installation and Maintenance Manual Then mark the fixing holes through the holes in the operator. In order to reach all 4 holes, you have to move the carrier. Remove the operator and drill fixing holes with a diameter of .165”...
  • Page 26 CS 80 MAGNEO — Installation and Maintenance Manual Connection of 120 V permanent power supply. Work on ellectrical equipment may only be performed by properly qualified staff (electricians) before starting with the installation, make sure that the power supply lines are dead (disconnected).
  • Page 27 CS 80 MAGNEO — Installation and Maintenance Manual Move the end stop to the end of the channel. The end stop must not fall out of the operator. Place the door panel inside the door frame. As the door panel is wider than the doorway, you will have to tilt it.
  • Page 28 CS 80 MAGNEO — Installation and Maintenance Manual Move the door panel to the desired closed position. Move the end stop next to the door panel and screw down tight (3.7 ft/lb). The end stop may only be moved to the inside by a certain dimension.

  • Page 29: Connection Diagrams

    CS 80 MAGNEO — Installation and Maintenance Manual 10. Connection diagrams In order to facilitate the connection of the wires, the different terminal blocks can be removed with pointed pliers. Connection terminals Main closing edge is the leading edge of the door.

  • Page 30: Cable Channel

    CS 80 MAGNEO — Installation and Maintenance Manual 11.Cable channel 2 " The cables for external accessories (sensors, 0 . 2 5 0 " 5 0 m m 6 m m pushbuttons etc.) have to be laid inside the cable channel as indicated in the picture.

  • Page 31: Connection Of Closing Edge Protection

    CS 80 MAGNEO — Installation and Maintenance Manual 12. Connection of closing edge protection This work may only be performed by properly qualified staff. Main closing edge is the leading edge of the door. Activating the sensor will disable automatic operation in the closing direction.

  • Page 32: Commissioning

    (plug it in) the green light indicator blinks and the operator has no function. You The CS 80 MAGNEO is now ready for opera- can access the door manually. tion. In order to make the operator ready for opera- How to switch the system from Low-Energy- to tion, you have to perform a learning cycle.
  • Page 33 CS 80 MAGNEO — Installation and Maintenance Manual Permanent Open Function via double-click Closing force This function can only be adjusted when a In case the door does not close properly due pushbutton is connected. to the door seals, you can increase the force...

  • Page 34: Operation Instructions

    When the system is delivered, the When the maximum speed is exceeded, the CS 80 MAGNEO is adjusted to AUTOMATIC operational resistance will increase in line Function. Depending on the installed acces- with the speed by which it is exceeded.
  • Page 35 CS 80 MAGNEO — Installation and Maintenance Manual Closing force In case the door does not close properly due to the door seals, you can increase the force with which the operator presses the door against the seal. In order to do so, set DIP switch 7 to „ON“...

  • Page 36: Daily Safety Checks

    Test badge has been fixed. The inspection and maintenance work has been documented. The CS 80 MAGNEO has to be switched off and secured against unintended and unauthorized switching on before performing maintenance work (cleaning or maintenance). Care Prior to first use and periodically thereafter, but at least once a year, the system must be che- cked and maintained by a qualified, knowledgeable technician.

  • Page 37: Troubleshooting Instructions

    CS 80 MAGNEO — Installation and Maintenance Manual 16. Troubleshooting Malfunction Possible causes Remedy The door does not No power supply. Switch on mains switch. respond. Loose cable connections. Connect cable connections The green LED light thoroughly indicator is off. Damaged power cord. Replace power cord.
  • Page 38 CS 80 MAGNEO — Installation and Maintenance Manual 16. Troubleshooting Malfunction Possible causes Remedy The red LED blinks The power mode switch of the Switch on mains switch off and 3 times at regular door has been switched to an intervals. other position.
  • Page 39 CS 80 MAGNEO — Installation and Maintenance Manual Operating cycle indicator When you press the „Reset“ button on the control unit for a short time, the door will open. In case the LED light indicator lights up for one second (yellow light), the system has performed more than 200,000 cycles. You should contact the Service Department in order to have the system checked.
  • Page 40 DORMA GmbH + Co. KG DORMA Platz 1 58256 EnnEPEtAl DORMA Automatics, Inc. DEutsCHlAnD 924 sherwood Drive tel. +49 2333 793-0 lake Bluff, Il 60044 +49 2333 793-4950 toll-Free: 800 367 6211 www.dorma.de 877 423 7999 DORMA GmbH + Co. KG DORMA Platz 1 tel.
