Parameter Access
Attribute Access Name
1 Get State
2 Get Instance type
3 Get Transport class
trigger
4 Get Produced
connection ID
5 Get Consumed
connection ID
6 Get Initial
communication
characteristics
7 Get Produced
connection size
8 Get Consumed
connection size
9 Get/Set Expected
package rate
12 Get Watchdog
timeout action
13 Get Produced
connection path
length
14 Get Produced
connection path
15 Get Consumed
connection path
length
16 Get Consumed
connection path
17 Get Production
inhibit time
Table 5.8 Instance 2 Attributes: Polled I/O
MG92F102
Programming Guide
Data type Description
USINT State of the object.
USINT Indicates either I/O or explicit message.
USINT Defines behavior of the connection.
UINT CAN identifier field when the connection transmits.
UINT CAN identifier field value that denotes message to be received.
USINT Defines the message group/groups across which productions and
consumptions associated with this connection occur.
UINT Maximum number of bytes transmitted across this connection.
UINT Maximum number of bytes received across this connection.
UINT Defines value used in transmission trigger timer and inactivity/
watchdog timer.
USINT Defines how to handle inactivity/watchdog timeout.
UINT Number of bytes in the produced connection path attribute.
Array of USINT Specifies the application object/objects whose data is to be produced
by these connection objects.
UINT Number of bytes in the consumed connection path attribute.
Array of USINT Specifies the application object/objects that are to receive the data
consumed by this connection object.
UINT Defines minimum time between new data production. This attribute is
required for I/O client connection.
