Appendix B: Mechanical Specification
Fig. 22
Anybus
®
CompactCom
™
B40 Modbus Serial User Manual
Outline of
connector board
Pin 1
Network
interface
Pin 1
Network
interface
Pin 1
Application
interface
M3: Standoff with internal thread, size M3
PCB layout
Top view
Outline of brick
Top view
33
38 (48)
FE
SCM-1202-130 1.1 en-US
