Hardware Design
Pin Signal Name
Ethernet based
networks, Copper
3 B_1P
4 B_1CEN
5 B_1N
7 B_2P
8 B_2CEN
9 B_2N
11 B_3P
12 B_3CEN
13 B_3N
15 B_4P
16 B_4CEN
17 B_4N
19 NW_LED4B
20 NW_LED4A
21 NW_LED3B
22 NW_LED3A
23 NW_LED2B
24 NW_LED2A
25 NW_LED1B
26 NW_LED1A
29 A_1P
30 A_1CEN
31 A_1N
33 A_2P
34 A_2CEN
35 A_2N
37 A_3P
38 A_3CEN
39 A_3N
41 A_4P
42 A_4CEN
43 A_4N
45
46
47
48
49
50
At the moment the following copper wired Ethernet protocols are available: EtherNet/IP and
PROFINET IRT. The speed of all these protocols is 100 Mb/s (using signal pairs 1-2 of each port).
PROFINET IRT is also available for fiber optic.
The LED signals are active high and should be connected to the respective LEDs via a resistor.
The pin types of the connector are defined in
network type on the following pages.
Anybus ® CompactCom ™ B40 Modbus Serial User Manual
Ethernet based DeviceNet
networks, fiber optic
B_RXP
B_SDA
B_RXN
B_SDP
B_SCL
B_SDN
B_TXEN
B_XDIS
B_TXP
B_TXN
NW_LED4B NW_LED4B
NW_LED4A NW_LED4A
NW_LED3B NW_LED3B
NW_LED3A NW_LED3A
NW_LED2B NW_LED2B
NW_LED2A NW_LED2A
NW_LED1B NW_LED1B
NW_LED1A NW_LED1A
A_RXP
A_SDA
A_RXN
A_SDP
A_SCL
A_SDN
A_TXEN
A_TXDIS
A_TXP
A_TXN
C_TX
C_RX
C_BUSP_N
GATE1
GATE2
Pin Types, p.
PROFIBUS
CC-Link
NW_LED4B NW_LED4B
NW_LED4A NW_LED4A
NW_LED3B NW_LED3B
NW_LED3A NW_LED3A
NW_LED2B NW_LED2B
NW_LED2A NW_LED2A
NW_LED1B NW_LED1B
NW_LED1A NW_LED1A
C_TX C_TX
C_RX C_RX
C_TXEN C_TXEN
GATE1 GATE1
GATE2 GATE2
4. The pin types are specified for each
