Modbus Application Interface
Register#
0x5004
0x5005
0x5100
0x5101
0x5102
0x5103
0x5200
0x5201
Anybus ® CompactCom ™ B40 Modbus Serial User Manual
Name Access
Network type Read only
Anybus Exception Code Read only
Data type
Read/
Write
Offline action
Read/
Write
Number of Write Read/
Parameters
Write
Number of Read
Read/
Parameters Write
Application switch 1
Read/
Write
Application switch 2 Read/
Write
Description
0x0089: PROFINET IRT
0x009B: EtherNet/IP
0x00: No exception
0x01: Application timeout
0x02:
Invalid device address
0x03: Invalid communication settings
0x04. Major unrecoverable application event
0x05: Waiting for application reset
0x06: Invalid process data configuration
0x07: Invalid application response
0x08: NVS memory checksum error
0x09: Functional Safety Module error
0x0A: Insufficient application implementation
0x0B: Missing serial number
0x0C: File system is corrupt
Data type of the parameters that are mapped to Write and Read
process data.
UINT8: 0x0004 (Default)
UINT16:
0x0005
R/W in SETUP state.
Read only in other states.
Action taken when the Anybus CompactCom is not in PROCESS_
ACTIVE state.
0x0000:
Clear "Read Process data area"
0x0001: No action (Default)
R/W in SETUP state.
Read only in other states.
Number of parameters mapped to Write process data.
If the value written is bigger than module can handle, the value will
automatically be adjusted to max possible value (according to
network) after the SETUP state.
R/W in SETUP state. Read only in other states.
Number of parameters mapped to Read process data.
If the value written is bigger than module can handle, the value will
automatically be adjusted to max possible value (according to
network) after the SETUP state.
R/W in SETUP state. Read only in other states.
This register can be used for the node address.
Value written to this register may be defined by DIP switches on
the application. See Network Configuration Switches, p.
This register can be used for defining stop bits and baud rate.
Value written to this register may be defined by DIP switches on
the application. See Network Configuration Switches, p.
12 (48)
28.
