Modbus Application Interface
6. Set the size of the Read Process Data area to register 0x5103. Data type (byte or word) is
configured with register 0x5100.
Example – Using the Modbus function Write Single Holding Register to configure
Read Process Data size 18 bytes. Assuming default value of register 0x5100, i.e. data type is
UINT8.
Address
0x05
7. The CompactCom is now ready to start communicating with the network master with the
configured settings. Start cyclical read/write of process data to register 0x0000- and 0x1000-.
Also consider to cyclically monitor the values of register 0x0FFD (Anybus Switch Status),
0x0FFE (LED status), and 0x0FFF (Anybus Status).
If a reset request is indicated in the Anybus Status register, the host application must reset
the CompactCom, and start the initialization sequence from step 1. See
p. 18.
Example – The Modbus function Read/Write Multiple Registers allows you to
both read and write registers with one command. In this example the status registers and
the read process data registers are read, at the same time as the write process data
registers are written.
Command:
Address
0x05
Response:
Address
0x05
The Anybus CompactCom will stay in state SETUP until values have been written to 0x5102 and
0x5103 (items no. 5 and 6 in the list above). The Anybus CompactCom will then change states to
WAIT_PROCESS, and the registers 0x5100-0x5103 will be read-only.
See also ..
• The Anybus State Machine, p. 42
