Hardware Design
4.2.4 Ethernet Based Networks (Copper)
The industrial networks, that use Ethernet for communication, share the same hardware design.
However, the firmware downloaded to the brick is different depending on network. Physically
they use the same set of pins in a similar way. At the moment Anybus CompactCom B40 Modbus
Serial is available for the following Ethernet based networks: EtherNet/IP and PROFINET IRT.
The brick supports dual network ports, signal group A should be connected to the left port (port
1) and signal group B to the right port (port 2) on the connector board, looking at the front, see
Connector Board for Copper Based Ethernet, p. 35
Signal Group
B
A
4.2.5 Ethernet Fiber Optic Networks
Ethernet fiber optic networks use more or less the same pins as copper based Ethernet networks.
The brick supports PROFINET fiber optic network (PROFINET IRT).
The brick supports dual network ports, signal group A is be connected to the left port (port 1)
and signal group B to the right port (port 2)on the connector board, looking at the front, see
Fiber Optic Conenctor LÄNK!!.
If the Anybus CompactCom B40 connector board is not to be used, please study the design
requirements for the Rx and SD channels, see
Channel Design Requirements, p.
preferred in order to minimize EMC disturbance.
Anybus ® CompactCom ™ B40 Modbus Serial User Manual
Signal Name Type
B_1P
I/O
B_1CEN Power
B_1N
I/O
B_2P
I/O
B_2CEN Power
B_2N
I/O
B_3P
I/O
B_3CEN Power
B_3N
I/O
B_4P
I/O
B_4CEN Power
B_4N
I/O
A_1P
I/O
A_1CEN Power
A_1N
I/O
A_2P
I/O
A_2CEN Power
A_2N
I/O
A_3P
I/O
A_3CEN Power
A_3N
I/O
A_4P
I/O
A_4CEN Power
A_4N
I/O
27. Furthermore, fiber optic connectors without metal are
Description
Pin
3 First pair, positive signal
4
Center tap voltage for first pair
5
First pair, negative signal
7
Second pair, positive signal
8 Center tap voltage for second pair
9
Second pair, negative signal
11
Third pair, positive signal. Used for Gigabit Ethernet.
12
Center tap voltage for third pair. Used for Gigabit
Ethernet.
13 Third pair, negative signal. Used for Gigabit Ethernet.
15
Fourth pair, positive signal. Used for Gigabit Ethernet.
16
Center tap voltage for fourth pair. Used for Gigabit
Ethernet.
17 Forth pair, negative signal. Used for Gigabit Ethernet.
29
First pair, positive signal
30 Center tap voltage for first pair
31
First pair, negative signal
33 Second pair, positive signal
34
Center tap voltage for second pair
35 Second pair, negative signal
37
Third pair, positive signal. Used for Gigabit Ethernet.
38 Center tap voltage for third pair. Used for Gigabit
Ethernet.
39 Third pair, negative signal. Used for Gigabit Ethernet.
41
Fourth pair, positive signal. Used for Gigabit Ethernet.
42 Center tap voltage for fourth pair. Used for Gigabit
Ethernet.
43
Forth pair, negative signal. Used for Gigabit Ethernet.
Rx Channel Design Requirements, p. 26
25 (48)
and SD
