STEVAL-STRKT01 Hardware Description
•
The STEVAL-STRKT01 LoRa® IoT tracker is
designed and optimized to implement the latest
technologies in IoT tracker applications such as
asset, people and animal tracking as well as fleet
management. Thanks to the STM32L072CZ
embedded in the CMWX1ZZABZ-091 LoRa® module
(by Murata), it allows acquiring position from Teseo-
LIV3F GNSS module and monitoring motion
(LIS2DW12) and environmental (HTS221 and
LPS22HB) sensors.
The board also transmits and receives data to and
from the cloud over a LoRaWAN™ network.
The STEVAL-STRKT01 is a LiPo battery operated
solution and implements low power strategies thanks
to an enhanced power/battery management design,
based on the STBC02 battery charger and the
ST1PS01 step-down converter, to ensure long battery
autonomy. The STUSB1600A addresses 5 V USB
Type-C port management and implements high
voltage protection features against short-circuits to
VBUS up to 28 V.
STEVAL-STRKT01 evaluation board
Hardware Overview
Latest info available at www.st.com
STEVAL-STRKT01
http://www.st.com/IoTLoraTracker
