B-L072Z-LRWAN1 hardware description
•
The B-L072Z-LRWAN1 Discovery kit embeds the CMWX1ZZABZ-091
LoRa®/Sigfox™ module (Murata). This Discovery kit allows users to develop
easily applications with the STM32L072CZ and the LoRa®/Sigfox™ RF
connectivity in one single module.
•
The B-L072Z-LRWAN1 Discovery kit has the full set of features available in the
STM32L0 series and offers ultra-low-power and LoRa®/Sigfox™ RF features.
The B-L072Z-LRWAN1
•
Discovery kit is a low-cost and easy-to-use development kit to quickly evaluate
and start a development with an STM32L072CZ microcontroller.
• The B-L072Z-LRWAN1 Discovery kit includes LoRa®/Sigfox™ RF interface,
LEDs, pushbuttons, antenna, Arduino™ Uno V3 connectors, USB 2.0 FS
connector in Micro-B format.
•
The integrated ST-LINK/V2-1 provides an embedded in-circuit debugger and
programmer for the STM32L0 MCUs.
• The LoRaWAN™ stack is certified class A and C compliant. It is available inside
the I-CUBE-LRWAN firmware package.The Sigfox™ stack is RCZ1, RCZ2, and
RCZ4 certified.
•
It is available inside the X-CUBE-SFOX expansion package.
• To help users setting up a complete node (LoRaWAN™, Sigfox™, or both), the
B-L072Z-LRWAN1 Discovery kit comes with the STM32 comprehensive free
software libraries and examples available with the STM32Cube package, as well
as a direct access to the Arm® Mbed Enabled™ resources at the http://mbed.org
website.
B-L072Z-LRWAN1 discovery kit
Hardware overview
Latest info available
at www.st.com
