Important hardware setup information
•
On the X-NUCLEO-GNSS1A1 expansion board
• the following jumpers must be open: J3, J5, J6, J7, J8 and J10.
• the following jumpers must be closed: J2, J4, J9, J11, J12, J13, J14 and J15.
•
On the X-NUCLEO-IKS01A2 expansion board, the solder bridge
SB25 must be unsoldered.
•
On the B-L072Z-LRWAN1 discovery board, the solder bridges SB32
and SB35 must be unsoldered.
FP-ATR-LORA1 hardware setup
on STM32 discovery and Expansion boards
