LOT NUMBER: DATE PURCHASED: Ellis Shutter Coffee Table Stock # BH48-084-099-45 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 866-942-5362 Pacific Standard Time: 8:30 a.m.
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Ellis Shutter Coffee Table MODEL # BH48-084-099-45 MADE IN CHINA MAXIMUM LOAD 90.7 kg / 200 lb...
Page 3
IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH DAMP CLOTH.
Page 4
Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Left Side Panel (Qty. 1) C- Right Side Panel (Qty. 1) D- Bottom Panel (Qty.
Page 5
Drawer Assembling Small Wood Dowel M4 x 38 mm Screw ⑥ (4 used in this step) (4 used in this step) ④ 1. Unpack the unit and confirm that you have all the hardware and required parts. 2. Insert four Small Wood Dowels (4) into the inner holes of the Drawer Back Panel (M) at both ends. Tap in with a rubber mallet, if necessary.
Page 6
Drawer Assembling M4 x 38 mm Screw ⑥ (4 used in this step) 4. Fasten two Drawer Bottom Supports (N) to the Drawer Back Panel (M) with four 38 mm Screws (6).
Page 7
Drawer Assembling 5. Slide the Drawer Bottom Panel (O) into the grooves between the Drawer Left and Right Side Panels (K and L) until fully inserted into the groove of the Drawer Back Panel (M).
Page 8
Drawer Assembling Cam Bolt Small Cam Lock Small Wood Dowel (6 used in this step) (6 used in this step) (6 used in this step) ③ ① ④ 6. Securely screw six Cam Bolts (3) into the designated small holes on the Drawer Front (J). 7.
Page 9
Assembly Instructions Cam Bolt (30 used in this step) ③ 8. Securely screw the Cam Bolts (3) into the designated small holes on the Top Panel (A), Bottom Panel (D), Back Panel (E) and Base Stretchers (G and H) using a Phillips screwdriver.
Page 10
Assembly Instructions Large Wood Dowel M4 x 38 mm Screw ⑥ (2 used in this step) (5 used in this step) ⑤ 9. Attach Top Front Stretcher (F) to Top Panel (A) with two Large Wood Dowels (5) and five 38 mm Screws (6).
Page 11
Assembly Instructions Large Cam Lock Large Wood Dowel (4 used in this step) (4 used in this step) ② ⑤ 10. Attach the Side Panels (B and C) to the Top Panel (A) with four Large Wood Dowels (5) and four Large Cam Locks (2).
Page 12
Assembly Instructions Large Wood Dowel M4 x 50 mm Screw ⑦ (4 used in this step) (4 used in this step) ⑤ 11. Attach the Bottom Panel (D) to the Side Panels (B and C) with four Large Wood Dowels (5) and four 50 mm Screws (7).
Page 13
Assembly Instructions Large Cam Lock Large Wood Dowel (12 used in this step) (8 used in this step) ② ⑤ 12. Attach the Back Panel (E) to the previous assembly with the Large Wood Dowels (5) and the Large Cam Locks (2).
Page 14
Assembly Instructions Large Cam Lock Large Wood Dowel (4 used in this step) (4 used in this step) ② ⑤ 13. Combine the Base Front Stretcher (G), Back Stretcher (H) and Side Stretchers (I) together with four Large Cam Locks (2) and four Large Wood Dowels (5).
Page 15
Assembly Instructions H/G/ I Large Cam Lock Large Wood Dowel (10 used in this step) (8 used in this step) ② ⑤ 14. Attach the assembled base to the Bottom Panel (D) with eight Large Wood Dowels (5) and ten Large Cam Locks (2).
Page 16
Assembly Instructions 15. Ask for assistance to lift the assembled unit upright and position it at the desired location. 16. Extend the sliding tracks on the Side Panels (B and C) all the way forward (including ball bearing cart). And then align the slide runners on the assembled drawer with the slide tracks and push the drawer carefully inside until it stops.
Page 17
Assembly Instructions 17. If necessary, adjust the pre-attached floor levelers at the bottom of Base Front Stretcher (G) to level the unit.
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
Page 19
NÚMERO DEL LOTE: FECHA DE COMPRA Mesa de centro Ellis Serie # BH48-084-099-45 ENSAMBLE REQUERIDO POR ADULTOS Si tiene alguna pregunta relacionada con el montaje o si faltan piezas, NO devuelva este producto al establecimiento donde lo adquirió. Por favor llame a nuestro número de servicio al cliente y tienen sus instrucciones y lista de piezas listo para proporcionar el nombre del modelo, el nombre o el número de parte de la fábrica: 866-942-5362...
Page 20
M Á X I M O P E S O R E C O M E N D A D O FABRICANTE: Whalen Furniture Manufacturing CATALOGO: Mesa de centro Ellis MODELO # BH48-084-099-45 HECHO EN CHINA CARGA MÁXIMA 90.7 kg / 200 lb CARGA MÁXIMA 13.7 kg / 30 lb...
Page 21
IMPORTANTE Antes de comenzar: Abra, identifique y cuente todas las partes antes del ensamble. Coloque las piezas sobre una superficie plana y no abrasiva. Tendrá que las partes identificadas en la página 4 de este manual de instrucciones. NOTA: ES MUY IMPORTANTE PARA EL USO DE GOMA CON LOS PERNSO DE MADERA. EL. EXCESO DE PEGAMENTO SE PUEDE LIMPIAR CON UN PAÑO HÚMEDO.
Page 22
Lista de partes y material de ferretería Le rogamos que lea completamente las instrucciones y verifique que todas las piezas y herramientas indicadas se encuentran presentes antes del comienzo del montaje. A- Panel superior (Cant. 1) B- Panel izquierdo (Cant. 1) C- Panel derecho (Cant.
Page 23
Ensamble del cajón Clavija de madera chica Perno de M4 x 38 mm ⑥ (4 usados en este paso) (4 usados en este paso) ④ 1. Desempacar la unidad y confirmar que se tiene todo el material de ferretería y partes requeridas. 2.
Page 24
Ensamble del cajón Perno de M4 x 38 mm ⑥ (4 usados en este paso) 4. Sujetar el 2 soportes inferiores del cajón (N) al panel posterior del cajón (M) con 4 pernos de 38 mm (6).
Page 25
Ensamble del cajón 5. Deslizar el panel inferior del cajón (O) en las ranuras entre los lados izquierdo y derecho del cajón (K y L) hasta que esté completamente insertado en la ranura del panel posterior del cajón (M).
Page 26
Ensamble del cajón Perno de fijación Tuerca de fijación chica Clavija de madera chica (6 usados en este paso) (6 usados en este paso) (6 usados en este paso) ③ ① ④ 6. Atornillar 6 pernos de fijación (3) en los agujeros chicos designados en el frente del cajón (J). 7.
Instrucciones de ensamblaje Perno de fijación (30 usados en este paso) ③ 8. Atornillar en los pernos de fijación (3) en los agujeros chicos designados en el panel superior (A), en el panel inferior (D), en el panel posterior (E) y en los soportes de base (G y H) usando el desarmador estrella.
Page 28
Instrucciones de ensamblaje Clavija de madera grande Perno de M4 x 38 mm ⑥ (2 usados en este paso) (5 usados en este paso) ⑤ 9. Adjuntar el soporte superior frontal (F) al panel superior (A) con 2 clavijas de madera grandes (5) y 5 pernos de 38 mm (6).
Page 29
Instrucciones de ensamblaje Tuerca de fijación grande Clavija de madera grande (4 usados en este paso) (4 usados en este paso) ② ⑤ 10. Adjuntar los paneles laterales (B y C) al panel superior (A) con 4 clavijas de madera grandes (5) y 4 tuercas de fijación grandes (2).
Page 30
Instrucciones de ensamblaje Clavija de madera grande Perno de M4 x 50 mm ⑦ (4 usados en este paso) (4 usados en este paso) ⑤ 11. Adjuntar el panel inferior (D) a los paneles laterales (B y C) con 4 clavijas de madera grandes (5) y 4 pernos de 50 mm (7).
Page 31
Instrucciones de ensamblaje Tuerca de fijación grande Clavija de madera grande (12 usados en este paso) (8 usados en este paso) ② ⑤ 12. Adjuntar el panel posterior (E) al ensamble previo con las clavijas de madera grandes (5) y las tuercas de fijación grandes (2).
Page 32
Instrucciones de ensamblaje Tuerca de fijación grande Clavija de madera grande (4 usados en este paso) (4 usados en este paso) ② ⑤ 13. Combinar el soporte frontal de base (G), el soporte posterior (H) y los soportes laterales (I) con 4 tuercas de fijación grandes (2) y 4 clavijas de madera grandes (5).
Page 33
Instrucciones de ensamblaje H/G/ I Tuerca de fijación grandes Clavijas de madera grandes (10 usados en este paso) (8 usados en este paso) ② ⑤ 14. Adjuntar el ensamble de la base al panel inferior (D) con 8 clavijas de madera grandes (5) y 10 tuercas de fijación grandes (2).
Page 34
Instrucciones de ensamblaje 15. Pedir asistencia para poner la unidad ensamblada en posición vertical y en el lugar deseado. 16. Extender los carriles de la corredera de baleros en los paneles laterales (B y C) todo el camino hacia enfrente (incluyendo el carrito de baleros). Luego alinear los complementos de corredera en el cajón ensamblado con los carriles de corredera y empujar el cajón hacia adentro hasta que tope.
Page 35
Instrucciones de ensamblaje 17. Si fuera necesario, ajustar los niveladores de piso preajustados a la parte inferior del soporte frontal de base (G) para nivelar la unidad.
Si esté producto tiene algun defecto de ensamble o material, o si tiene alguna falla en uso normal, nosotros lo repararemos o lo remplazaremos hasta por un año a partir de la fecha de compra. Todo producto de Whalen Furniture es diseñado para alcanzar sus espectativas más altas. Nosotros le garantizamos que inmediatamente podrá...
